Sanyo PLV-Z3000 Service Manual

- 57 -
No. Adjustment Item Initial Value Range Input source / Description
14 FRP_Pos 420 0 - 2047
15 OSD_Pos 0 0 - 31
16 OSD_Pth 512 0 - 1023
17 GammaCtrl 965 0 - 1023
18 GammaCtrl_Ena 1 0 - 1 Gamma correction enable 1 : Enable 0 : Disable
19 GammaCtrl_PreEna 1 0 - 1 Pre-gamma correction enable 1 : Enable 0 : Disable
20 REF_GatePos 2 0 - 1023
21 REF_GateDur 0 0 - 1023
22 ImgQuaCtrl 64 0 - 511
23 ImgQuaCtrl_DCEna 1 0 - 1 V-Line DC oset correction enable 1 : Enable 0 : Disable
24 BasePos_R 0 0 - 11
25 BasePos_G 0 0 - 11
26 BasePos_B 0 0 - 11
27 RGB_SideMode 0 0 - 1
28 Side_COEF_1R 0 0 - 2047 MIN<---->MAX cyclic motion
29 Side_COEF_1G 0 0 - 2047 MIN<---->MAX cyclic motion
30 Side_COEF_1B 0 0 - 2047 MIN<---->MAX cyclic motion
31 Side_COEF_2R 0 0 - 2047 MIN<---->MAX cyclic motion
32 Side_COEF_2G 0 0 - 2047 MIN<---->MAX cyclic motion
33 Side_COEF_2B 0 0 - 2047 MIN<---->MAX cyclic motion
34 Side_COEF_3R 0 0 - 2047 MIN<---->MAX cyclic motion
35 Side_COEF_3G 0 0 - 2047 MIN<---->MAX cyclic motion
36 Side_COEF_3B 0 0 - 2047 MIN<---->MAX cyclic motion
37 Side_COEF_4R 0 0 - 2047 MIN<---->MAX cyclic motion
38 Side_COEF_4G 0 0 - 2047 MIN<---->MAX cyclic motion
39 Side_COEF_4B 0 0 - 2047 MIN<---->MAX cyclic motion
40 Side_COEF_HMin 0 0 - 4095
41 Side_COEF_HMax 4095 0 - 4095
42 Side_COEF_VMin 0 0 - 4095
43 Side_COEF_VMax 4095 0 - 4095
44 CRSTLK_COEF_R 0 0 - 2047
45 CRSTLK_COEF_G 0 0 - 2047
46 CRSTLK_COEF_B 0 0 - 2047
47 CRSTLK_BASE_R 0 0 - 4095
48 CRSTLK_BASE_G 0 0 - 4095
49 CRSTLK_BASE_B 0 0 - 4095
50 CRSTLK_COEF_R_C 0 0 - 2047 MIN<---->MAX cyclic motion
51 CRSTLK_COEF_R_S 128 0 - 255
52 CRSTLK_COEF_R_E 128 0 - 255
53 CRSTLK_COEF_G_C 0 0 - 2047 MIN<---->MAX cyclic motion
54 CRSTLK_COEF_G_S 128 0 - 255
55 CRSTLK_COEF_G_E 128 0 - 255
56 CRSTLK_COEF_B_C 0 0 - 2047 MIN<---->MAX cyclic motion
57 CRSTLK_COEF_B_S 128 0 - 255
58 CRSTLK_COEF_B_E 128 0 - 255
59 ColshdCtrl 16 0 - 1023
60 ColshdCtrl_Ena 1 0 - 1 Gamma correction enable 1 : Enable 0 : Disable
61 ColshdCtrl_PreEna 0 0 - 1 Pre-Gamma correction enable 1 : Enable 0 : Disable
62 Colshd_RLMin 374 0 - 1023
63 Colshd_RLMid2 421 0 - 1023
64 Colshd_RLMid1 451 0 - 1023
65 Colshd_RLMax 482 0 - 1023
66 Colshd_GLMin 362 0 - 1023
67 Colshd_GLMid2 407 0 - 1023
68 Colshd_GLMid1 434 0 - 1023
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
