Sanyo PLV-Z3000 Service Manual

- 58 -
No. Adjustment Item Initial Value Range Input source / Description
69 Colshd_GLMax 460 0 - 1023
70 Colshd_BLMin 348 0 - 1023
71 Colshd_BLMid2 387 0 - 1023
72 Colshd_BLMid1 409 0 - 1023
73 Colshd_BLMax 430 0 - 1023
74 Colshd_RV8_RLMid3 562 0 - 1023
75 Colshd_RV8_RLMid2 620 0 - 1023
76 Colshd_RV8_RLMid1 702 0 - 1023
77 Colshd_RV8_RLMax 764 0 - 1023
78 Colshd_RV8_GLMid3 523 0 - 1023
79 Colshd_RV8_GLMid2 565 0 - 1023
80 Colshd_RV8_GLMid1 627 0 - 1023
81 Colshd_RV8_GLMax 676 0 - 1023
82 Colshd_RV8_BLMid3 474 0 - 1023
83 Colshd_RV8_BLMid2 500 0 - 1023
84 Colshd_RV8_BLMid1 536 0 - 1023
85 Colshd_RV8_BLMax 564 0 - 1023
86 Colshd_Pre_Tbl 0 0 - 255
87 Colshd_Tbl_COEF 0 0 - 128
88 Pixel_CONT_Out 2048 0 - 4095
89 H_Sync 4 0 - 2047
90 V_Sync 0 0 - 255
91 Flicker 0 0 - 1 0 : Notmal 1 : Flicker adjustment Mode
92 ENBY_Up01 48 0 - 255
93 ENBY_Down01 534 0 - 1023
94 LV0P_Start 36 0 - 63
95 LV0P_Width 14 0 - 15
96 MSEL_Start01 28 0 - 2047
97 MSEL_Start02 92 0 - 2047
98 MSEL_Start03 141 0 - 2047
99 MSEL_Start04 190 0 - 2047
100 MSEL_Start05 239 0 - 2047
101 MSEL_Start06 288 0 - 2047
102 MSEL_Start07 337 0 - 2047
103 MSEL_Start08 386 0 - 2047
104 MSEL_Start09 435 0 - 2047
105 MSEL_Start10 508 0 - 2047
106 MSEL_PLS_L_01 21 0 - 255
107 MSEL_PLS_L_02_09 43 0 - 255
108 MSEL_PLS_L_10 20 0 - 255
109 CRCT_UNEVN_Sel 0 0 - 1
110 CRCT_UNEVN_QUAPLS_R 1 0 - 2047
111 CRCT_UNEVN_QUAPLS_G 1 0 - 2047
112 CRCT_UNEVN_QUAPLS_B 1 0 - 2047
113 CRCT_UNEVN_QUAMNS_R 1 0 - 2047
114 CRCT_UNEVN_QUAMNS_G 1 0 - 2047
115 CRCT_UNEVN_QUAMNS_B 1 0 - 2047
116 CRCT_UNEVN_SHIFT_R 0 0 - 15
117 CRCT_UNEVN_SHIFT_G 0 0 - 15
118 CRCT_UNEVN_SHIFT_B 0 0 - 15
119 CRSTLK_COEF1_R_C 0 0 - 2047
120 CRSTLK_COEF1_R_S 128 0 - 255
121 CRSTLK_COEF1_R_E 128 0 - 255 MIN<---->MAX cyclic motion
122 CRSTLK_COEF1_G_C 0 0 - 2047
123 CRSTLK_COEF1_G_S 128 0 - 255
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
