Sanyo PLV-Z3000 Service Manual

- 59 -
No. Adjustment Item Initial Value Range Input source / Description
124 CRSTLK_COEF1_G_E 128 0 - 255 MIN<---->MAX cyclic motion
125 CRSTLK_COEF1_B_C 0 0 - 2047
126 CRSTLK_COEF1_B_S 128 0 - 255
127 CRSTLK_COEF1_B_E 128 0 - 255 MIN<---->MAX cyclic motion
128 CRSTLK_COEF2_BASE_R 0 0 - 4095
129 CRSTLK_COEF2_BASE_G 0 0 - 4095
130 CRSTLK_COEF2_BASE_B 0 0 - 4095
131 CRSTLK_COEF2_R_C 0 0 - 2047
132 CRSTLK_COEF2_R_S 128 0 - 255
133 CRSTLK_COEF2_R_E 128 0 - 255 MIN<---->MAX cyclic motion
134 CRSTLK_COEF2_G_C 0 0 - 2047
135 CRSTLK_COEF2_G_S 128 0 - 255
136 CRSTLK_COEF2_G_E 128 0 - 255 MIN<---->MAX cyclic motion
137 CRSTLK_COEF2_B_C 0 0 - 2047
138 CRSTLK_COEF2_B_S 128 0 - 255
139 CRSTLK_COEF2_B_E 128 0 - 255 MIN<---->MAX cyclic motion
140 OutputLimitMax_R 4095 0 - 4095
141 OutputLimitMax_G 4095 0 - 4095
142 OutputLimitMax_B 4095 0 - 4095
143 ODEn 1 0 - 1 Over Drive function enable 1 : Enable 0 : Disable
144 ODDiPrec 0 0 - 3 Over Drive [Low]
0 0 - 3 Over Drive [High]
145 ODLUT 2 0 - 3 Over Drive [Low]
3 0 - 3 Over Drive [High]
146 ODTemp_A_R 16 0 - 63 Over Drive [Low]
16 0 - 63 Over Drive [High]
147 ODTemp_A_G 16 0 - 63 Over Drive [Low]
16 0 - 63 Over Drive [High]
148 ODTemp_A_B 16 0 - 63 Over Drive [Low]
16 0 - 63 Over Drive [High]
149 ODTemp_B_R 0 0 - 4095 Over Drive [Low]
0 0 - 4095 Over Drive [High]
150 ODTemp_B_G 0 0 - 4095 Over Drive [Low]
0 0 - 4095 Over Drive [High]
151 ODTemp_B_B 0 0 - 4095 Over Drive [Low]
0 0 - 4095 Over Drive [High]
152 ODTestModeEn 0 0 - 1 Over Drive ckeck mode enable 1 : Enable 0 : disable
153 OD_OSDLvl_A 0 0 - 4095
154 OD_OSDLvl_B 0 0 - 4095
155 ODFrpSel 0 0 - 1
156 OD_OSDRGBSel 0 0 - 7
157 ODTrigPos_H 0 0 - 511
158 ODTrigPos_V 0 0 - 2047
159 ODLUTMode 0 0 - 1
160 ODLUTSize 0 0 - 9
161 VideoRRefCont_H 0 0 - 4095
162 VideoRRefCont_L 0 0 - 4095
163 DCOset_MNS_R 0 0 - 1023 Normal
0 0 -1023 R/L Reverse
164 DCOset_MNS_R_01 2008 0 - 2047 Normal
0 0 - 2047 R/L Reverse
165 DCOset_MNS_R_02 2024 0 - 2047 Normal
0 0 - 2047 R/L Reverse
166 DCOset_MNS_R_03 2032 0 - 2047 Normal
0 0 - 2047 R/L Reverse
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
