Sanyo PLV-Z3000 Service Manual

- 60 -
No. Adjustment Item Initial Value Range Input source / Description
167 DCOset_MNS_R_04 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
168 DCOset_MNS_R_05 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
169 DCOset_MNS_R_06 0 0 - 2047 Normal
2032 0 - 2047 R/L Reverse
170 DCOset_MNS_R_07 0 0 - 2047 Normal
2024 0 - 2047 R/L Reverse
171 DCOset_MNS_R_08 0 0 - 2047 Normal
2008 0 - 2047 R/L Reverse
172 DCOset_MNS_R_09 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
173 DCOset_MNS_R_010 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
174 DCOset_PLS_R 0 0 - 1023 Normal
0 0 - 1023 R/L Reverse
175 DCOset_PLS_R_01 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
176 DCOset_PLS_R_02 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
177 DCOset_PLS_R_03 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
178 DCOset_PLS_R_04 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
179 DCOset_PLS_R_05 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
180 DCOset_PLS_R_06 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
181 DCOset_PLS_R_07 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
182 DCOset_PLS_R_08 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
183 DCOset_PLS_R_09 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
184 DCOset_PLS_R_10 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
185 VideoGRefCont_H 0 0 - 4095
186 VideoGRefCont_L 0 0 - 4095
187 DCOset_MNS_G 0 0 - 1023 Normal
0 0 - 1023 R/L Reverse
188 DCOset_MNS_G_01 0 0 - 2047 Normal
2008 0 - 2047 R/L Reverse
189 DCOset_MNS_G_02 0 0 - 2047 Normal
2024 0 - 2047 R/L Reverse
190 DCOset_MNS_G_03 0 0 - 2047 Normal
2032 0 - 2047 R/L Reverse
191 DCOset_MNS_G_04 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
192 DCOset_MNS_G_05 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
193 DCOset_MNS_G_06 2032 0 - 2047 Normal
0 0 - 2047 R/L Reverse
194 DCOset_MNS_G_07 2024 0 - 2047 Normal
0 0 - 2047 R/L Reverse
195 DCOset_MNS_G_08 2008 0 - 2047 Normal
0 0 - 2047 R/L Reverse
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
