Sanyo PLV-Z3000 Service Manual

- 62 -
No. Adjustment Item Initial Value Range Input source / Description
0 0 - 2047 R/L Reverse
225 DCOset_PLS_B_03 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
226 DCOset_PLS_B_04 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
227 DCOset_PLS_B_05 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
228 DCOset_PLS_B_06 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
229 DCOset_PLS_B_07 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
230 DCOset_PLS_B_08 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
231 DCOset_PLS_B_09 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
232 DCOset_PLS_B_10 0 0 - 2047 Normal
0 0 - 2047 R/L Reverse
Group:102 LCD Panel Service (9040)
0 F00_R 8 0 - 31
R/L, U/D, data reverce, DX reverce, DYreverce1 F00_G 9 0 - 31
2 F00_B 8 0 - 31
3 F02_R 1 0 - 4095
Pre-charge ON/OFF set4 F02_G 1 0 - 4095
5 F02_B 1 0 - 4095
6 F06_R 3776 0 - 4095
Pre-charge positive pole output step set7 F06_G 3776 0 - 4095
8 F06_B 3776 0 - 4095
9 F07_R 512 0 - 4095
Pre-charge negative pole output step set10 F07_G 512 0 - 4095
11 F07_B 512 0 - 4095
12 F09_R 170 0 - 4095
VCOM output voltage set13 F09_G 170 0 - 4095
14 F09_B 170 0 - 4095
15 F0E_R 2 0 - 4095
Drive condition set 116 F0E_G 2 0 - 4095
17 F0E_B 2 0 - 4095
18 F0F_R 16 0 - 4095
Drive condition set 2
19 F0F_G 16 0 - 4095
20 F0F_B 16 0 - 4095
Group:200 Option
0 Logo Select 0 0 - 1 0 : Menu 1 : Disable (2 : For China Logo)
1 RS232C Baudrate 0 0 - 1 0 : 19200bps 1: 9600bps
5 PW Debug Command Enable 0 0 - 1 0 : Disable 1 : Enable
10 Factory use only
20 Projector Time Reset 0 0 - 10 Value vhange 0 --> 10 Projector Time reset
60 Super Standby Mode 0 0 - 1 0: Normal Standby Mode, 1: Super Standby Mode
61 No signal lamp mode 0 0 - 1 0: Disable 1: Enable
110 Overdrive 1 / 1 / 0 / 0 / 1 / 2 / 0 / 0 0 - 2
Overdrive setting 0 : Off 1 : Low 2 : High
For select Image menu data
B-Cinema / C-Cinema / P-Cinema / Natural / Living / Dynamic /
x.v.Color / No signal
Group:201 Option (Signal)
0 FrameLock Option 0 0 - 1 FrameLock setting 0 : Normal 1 : Allway Off
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
