Sanyo PLV-Z3000 Service Manual

- 63 -
No. Adjustment Item Initial Value Range Input source / Description
1 Dither Enable 0 0 - 1 0 : Dither function disable 1 : Dither function enable
Group:210 Lamp Control
0 Dimmer SW 0 0 - 1 0 : Auto (User setting) 1 : Manual
1 Manual Control 0 0 - 15 Dimmer Control Level ( 0: dark 1: bright)
2 DIMMER_CTRL_LEVEL0 5/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 00 (darkest)
3 DIMMER_CTRL_LEVEL1 9/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 01
4 DIMMER_CTRL_LEVEL2 14/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 02
5 DIMMER_CTRL_LEVEL3 18/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 03
6 DIMMER_CTRL_LEVEL4 23/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 04
7 DIMMER_CTRL_LEVEL5 27/0 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 05
8 DIMMER_CTRL_LEVEL6 32/14 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 06
9 DIMMER_CTRL_LEVEL7 36/21 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 07
10 DIMMER_CTRL_LEVEL8 41/28 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 08
11 DIMMER_CTRL_LEVEL9 45/35 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 09
12 DIMMER_CTRL_LEVEL10 50/42 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 10
13 DIMMER_CTRL_LEVEL11 54/49 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 11
14 DIMMER_CTRL_LEVEL12 59/56 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 12
15 DIMMER_CTRL_LEVEL13 64/63 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 13
16 DIMMER_CTRL_LEVEL14 69/69 0 - 255
APL level threshold (AUTO1/AUTO2)
Below this data Dimmer level 114
3~16 Dimmer control Lamp mode AUTO1 : Display AUTO1 setting data Enable data exchange
Lamp mode AUTO2 : Display AUTO2 setting data Enable data exchange
Lamp mode NORMAL, ECO : Display AUTO2 setting data Disable data exchange
17 DIMMER_AVERAGE_POINT 4 1 - 16
18 DIMMER_AVERAGE_DATA - 0 - 255
19 DIMMER_LEVEL_AUTO - 0 - 15
20 DIMMER_LEVEL_NORMAL 15 0 - 15
21 DIMMER_LEVEL_ECO 0 0 - 15
23 VOLTAGE_LEVEL - 0 - 255 Lamp voltage : Read only
Group:211 Lamp iris
0 Lamp Iris Close Limit Value 32 0 - 510
1 Lamp Iris Open Limit Value 480 1 - 511
4 Lamp IRIS Ave Time 1 1 - 8
5 Lamp IRIS Move Step 304 1 - 510
8 Lamp IRIS SW 0 0 - 1
9 Lamp IRIS Manual 256 1 - 511
10 Lamp IRIS Close Rate 50/60/70/127/127/0/127 0 - 254
Brilliant / Creative / Pure/ Natural / Living / Dynamic /x.v.Color
0 : close 254 : open
12 Lamp IRIS Color Adj Open Rate 128 0 - 254 0 : close 254 : open
13 Lamp Iris Repeat mode 0 0 - 8
Valur data in not "0", opening and closing of Iris is repeated
according to the set point of No.14, 15.
1 : 2V Sync 2 : 4V Sync 3 : 6V Sync 4 : 8V Sync
5 : 10VSync 6 : 12V Sync 7 : 14V Sync 8 : 16V sync
14 Repeat Mode Close Value 32 0 - 510 The value set as PWM_Min when the value of No.13 is except 0
15 Repeat Mode Open Value 480 1 - 510 The value set as PWM_Max when the value of No.13 is except 0
Group:212 Costum Gamma Coefficient
0 Costum Gamma -R step 0 18 1 - 512
1 Costum Gamma -R step 512 20 1 - 512
2 Costum Gamma -R step 1024 24 1 - 512
3 Costum Gamma -R step 1536 26 1 - 512
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
