Sanyo PLV-Z3000 Service Manual

- 64 -
No. Adjustment Item Initial Value Range Input source / Description
4 Costum Gamma -R step 2048 28 1 - 512
5 Costum Gamma -R step 2560 32 1 - 512
6 Costum Gamma -R step 3072 36 1 - 512
7 Costum Gamma -R step 3584 40 1 - 512
8 Costum Gamma -R step 4096 44 1 - 512
9 Costum Gamma -G step 0 18 1 - 512
10 Costum Gamma -G step 512 20 1 - 512
11 Costum Gamma -G step 1024 24 1 - 512
12 Costum Gamma -G step 1536 26 1 - 512
13 Costum Gamma -G step 2048 28 1 - 512
14 Costum Gamma -G step 2560 32 1 - 512
15 Costum Gamma -G step 3072 36 1 - 512
16 Costum Gamma -G step 3584 40 1 - 512
17 Costum Gamma -G step 4096 44 1 - 512
18 Costum Gamma -B step 0 18 1 - 512
19 Costum Gamma -B step 512 20 1 - 512
20 Costum Gamma -B step 1024 24 1 - 512
21 Costum Gamma -B step 1536 26 1 - 512
22 Costum Gamma -B step 2048 28 1 - 512
23 Costum Gamma -B step 2560 32 1 - 512
24 Costum Gamma -B step 3072 36 1 - 512
25 Costum Gamma -B step 3584 40 1 - 512
26 Costum Gamma -B step 4096 44 1 - 512
Group:230 DOOR CONTROL
1 First 200 0 - 2000 Unit : ms
2 Low time 0 0 - 2000 Unit : ms
3 High time 100 0 - 2000 Unit : ms
4 After arrival 500 0 - 2000 Unit : ms
5 Limit 50(=5000ms) 0 - 200
7 Open count 0 0 - 30000
8 Close count 0 0 - 30000
9 reset open counter 1 0 - 1
10 reset close counter 1 0 - 1
11 Exhibition 0 0 - 1
12 Demo Time 22(=2200ms) 0 - 200
13 Blink time 2(60sec) 0 - 10
Group:231 Cinema Filter
0 First 200 (ms) 0 - 2000 All velocity driving time when beginning to open and shut
1 Low time 0 0 - 2000 At low-speed driving, Low output time. Unit : ms
2 High time 100 0 - 2000 At low-speed driving, Low output time. Unit : ms
3 Wait start 0 0 - 2000 Waiting time at "Image mode" change. Unit : ms
4 After arrival 500 0 - 2000 After position detect, driving time. Unit : ms
5 Limit 30 (=3000ms) 0 - 200 Waiting time setting. (Operation comple)
6 Filter In count 0 0 - 30000
7 Filter Out count 0 0 - 30000
8 Life Test Mode 0 0 - 1
Life test mode setting.
0 : Normal 1 : repetition IN/OUT
Group:232 Cinema Filter Manual Mode
0 Manual Mode 0 0 - 1
Manual mode setting
0 : Image mode linking 1 : Compulsion operation mode
(Do not keep EEPROM)
1 Manual move 0 0 - 1
Filter movement direction
0 : IN -> OUT 1 : OUT -> IN
Efective Manual Mode "1" only
(Do not keep EEPROM)
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
