Sanyo PLV-Z3000 Service Manual

- 66 -
No. Adjustment Item Initial Value Range Input source / Description
52 Normal TempA Error 44/44/41/- -5 - 100 Normal_Temp. -sensor A_Shutdown-temp.
53 Normal TempB Error 58/58/62/- -5 - 100 Normal_Temp. -sensor B_Shutdown-temp.
54 Normal TempC Error 58/58/55/- -5 - 100 Normal_Temp. -sensor C_Shutdown-temp.
55 Normal TempB-A Error 33/33/40/- 0 - 100 Normal_Temp. -sensor (B-A)_Shutdown-temp.
56 Normal TempC-A Error 26/26/40/- 0 - 100 Normal_Temp. -sensor (C-A)_Shutdown-temp.
57 Eco Fan1 Min 750/750/1110/1110 510 - 4500
Eco_Temp.-Min revolution
58 Eco Fan2 Min 1350/1350/1920/- 510 - 6510
59 Eco Fan3 Min 1230/1230/1800/1800 510 - 4500
60 Eco Fan4 Min 1710/1710/2265/4050 510 - 6510
61 Eco Fan5 Min 1110/1110/1470/2550 510 - 6510
62 Eco Fan1 Max 1140/1140/1200/1200 510 - 4500
Eco_Temp.-Max revolution
63 Eco Fan2 Max 1485/1485/2010/- 510 - 6510
64 Eco Fan3 Max 1665/1665/1800/1800 510 - 4500
65 Eco Fan4 Max 3840/3840/4050/4050 510 - 6510
66 Eco Fan5 Max 2745/2745/2745/2745 510 - 6510
67 Eco TempA Low 32/32/26 -5 - 100 Ecol_Temp. -sensor A_Control_Start-temp.
68 Eco TempA High 36/36/35 -5 - 100 Ecol_Temp. -sensor A_Control_End-temp.
69 Eco TempB Low 53/53/55 -5 - 100 Ecol_Temp. -sensor B_Control_Start-temp.
70 Eco TempB High 56/56/59 -5 - 100 Ecol_Temp. -sensor B_Control_End-temp.
71 Eco TempC Low 50/50/47 -5 - 100 Ecol_Temp. -sensor C_Control_Start-temp.
72 Eco TempC High 55/55/50 -5 - 100 Ecol_Temp. -sensor C_Control_End-temp.
73 Eco TempA Error 44/44/41/- -5 - 100 Eco_Temp. -sensor A_Shutdown-temp.
74 Eco TempB Error 66/66/62/- -5 - 100 Eco_Temp. -sensor B_Shutdown-temp.
75 Eco TempC Error 59/59/53/- -5 - 100 Eco_Temp. -sensor C_Shutdown-temp.
76 Eco TempB-A Error 38/38/40/- 0 - 100 Eco_Temp. -sensor (B-A)_Shutdown-temp.
77 Eco TempC-A Error 28/28/40/- 0 - 100 Eco_Temp. -sensor (C-A)_Shutdown-temp.
78 Auto Watt Max Fan1 Min 1380/1380/1545/1545 510 - 4500
Dimmer_Bright-Max_Temp-Min revolution
79 Auto Watt Max Fan2 Min 2220/2220/3420/- 510 - 6510
80 Auto Watt Max Fan3 Min 1905/1905/2100/2100 510 - 4500
81 Auto Watt Max Fan4 Min 2595/2595/4050/5115 510 - 6510
82 Auto Watt Max Fan5 Min 1905/1905/2745/3165 510 - 6510
83 Auto Watt Max Fan1 Max 1470/1470/1710/1710 510 - 4500
Dimmer_Bright-Max_Temp-Max revolution
84 Auto Watt Max Fan2 Max 2460/2460/3630/- 510 - 6510
85 Auto Watt Max Fan3 Max 1905/1905/2100/2100 510 - 4500
86 Auto Watt Max Fan4 Max 5115/5115/5115/5115 510 - 6510
87 Auto Watt Max Fan5 Max 3240/3240/3240/3240 510 - 6510
88 Auto Watt Min Fan1 Min 750/750/1110/1110 510 - 4500
Dimmer_Bright-Min_Temp-Min revolution
89 Auto Watt Min Fan2 Min 1350/1350/1920/- 510 - 6510
90 Auto Watt Min Fan3 Min 1230/1230/1800/1800 510 - 4500
91 Auto Watt Min Fan4 Min 1710/1710/2265/4050 510 - 6510
92 Auto Watt Min Fan5 Min 1110/1110/1470/2550 510 - 6510
93 Auto Watt Min Fan1 Max 1140/1140/1200/1200 510 - 4500
Dimmer_Bright-Min_Temp-Max revolution
94 Auto Watt Min Fan2 Max 1485/1485/2010/- 510 - 6510
95 Auto Watt Min Fan3 Max 1665/1665/1800/1800 510 - 4500
96 Auto Watt Min Fan4 Max 3840/3840/4050/4050 510 - 6510
97 Auto Watt Min Fan5 Max 2745/2745/2745/2745 510 - 6510
98 Auto TempA Low 32/32/26/- -5 - 100 Dimmer_Temp. -sensor A_Control_Start-temp.
99 Auto TempA High 36/36/35/- -5 - 100 Dimmer_Temp. -sensor A_Control_End-temp.
100 Auto TempB Low 53/53/55/- -5 - 100 Dimmer_Temp. -sensor B_Control_Start-temp.
101 Auto TempB High 56/56/59/- -5 - 100 Dimmer_Temp. -sensor B_Control_End-temp.
102 Auto TempC Low 50/50/47/- -5 - 100 Dimmer_Temp. -sensor C_Control_Start-temp.
103 Auto TempC High 55/55/51/- -5 - 100 Dimmer_Temp. -sensor C_Control_End-temp.
104 Auto TempA Error 44/44/41/- -5 - 100 Dimmer_Temp. -sensor A_Shutdown-temp.
105 Auto TempB Error 66/66/62/- -5 - 100 Dimmer_Temp. -sensor B_Shutdown-temp.
106 Auto TempC Error 59/59/55/- -5 - 100 Dimmer_Temp. -sensor C_Shutdown-temp.
107 Auto TempB-A Error 38/38/40/- 0 - 100 Dimmer_Temp. -sensor (B-A)_Shutdown-temp.
108 Auto TempC-A Error 28/28/40/- 0 - 100 Dimmer_Temp. -sensor (C-A)_Shutdown-temp.
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
