Sanyo PLV-Z3000 Service Manual

- 68 -
No. Adjustment Item Initial Value Range Input source / Description
Group :260 AUTO CALIBRATION
0 Execute Calibration 0 0 - 1
Auto calibration will execute when the value changes. (For PC
white 100% Adjustment.)
1 Loop Count 8 1 - 30 Maximum times of calibration
2 Auto Status 0 0 / 1 / 9
Read only Auto calibration result
0: End correctly 1 : On Adjustment 9 : End at Error
3 AutoWait 3 1 - 20 Wait value
4 CHECK - Tolerance 4 1 - 255 Offset Final check Tolerance
5 Time out wait 20 1 - 255 Wait time (sec)
Group:261 AUTO CALIBRATION (RGB)
0 OFFSET AREA H START 975 0 - 1000 Black Level H
1 OFFSET AREA V START 500 0 - 1000 Black Level V
2 OFFSET AREA V START 25 0 - 1000 White Level H
3 GAIN AREA V START 500 0 - 1000 White Level V
4 Image AREA H WIDTH 13 0 - 4095 White / Black Level Width
5 Image AREA V HIGHT 9 0 - 4095 White / Black Level Hight
6 OFFSET Target 20 0 - 1023 Black Level Adjustment Target Value
7 OFFSET Tolerance 1 1 - 1023 Black Level Adjustment Tolerance
8 Gain Target 955 0 - 1023 White Level Adjustment Target Value
9 GAIN Tolerance 1 1 - 1023 White Level Adjustment Tolerance
10 Image Level Tolerance 2 1 - 255 Image Level Tolerance
Group:262 AUTO CALIBRATION (CVBS / S-VIDEO)
0 Y Image Area Start X 20 0 - 1000 Y Image Area Start X
1 Y Image Area Start Y 200 0 - 1000 Y Image Area Start Y
6 Image Area H Width 8 0 - 4095 Image Area H Width
7 Image Area V Hight 8 0 - 4095 Image Area V Hight
8 Y Target Level 875 0 - 1023 Y Target Level
11 Gain Tolerance 1 1 - 255 Gain Tolerance
12 Image Level Tolerance 2 1 - 255 Image Level Tolerance
Group:264 AUTO CALIBRATION (YCbCr)
0 Y-OFFSET AREA H START 925 0 - 1000 Y-OFFSET AREA H START
1 Y-OFFSET AREA V STAR 500 0 - 1000 Y-OFFSET AREA V STAR
2 CB - OFFSET AREA H START 925 0 - 1000 CB - OFFSET AREA H START
3 CB - OFFSET AREA V START 500 0 - 1000 CB - OFFSET AREA V START
4 CR - OFFSET AREA H START 925 0 - 1000 CR - OFFSET AREA H START
5 CR - OFFSET AREA V START 500 0 - 1000 CR - OFFSET AREA V START
6 Y - GAIN AREA H START 50 0 - 1000
7 Y - GAIN AREA V START 500 0 - 1000
8 CB - GAIN AREA H START 800 0 - 1000
9 CB - GAIN AREA V START 500 0 - 1000
10 CR - GAIN AREA H START 700 0 - 1000
11 CR - GAIN AREA V START 500 0 - 1000
12 Image AREA H WIDTH 13 0 - 4095 Y, CB, CR Area H Widht
13 Image AREA V HIGHT 9 0 - 4095 Y, CB, CR Area V Widht
14 Y - OFFSET TARGET 4 0 - 1023
15 CB OFFSET TARGET 512 0 - 1023
16 CR OFFSET TARGET 512 0 - 1023
17 Y - GAIN TARGET 810 0 - 1023
18 CB - GAIN TARGET 894 0 - 1023
19 CR - GAIN TARGET 894 0 - 1023
20 OFFSET Tolerance 1 1 - 255 OFFSET Tolerance
21 GAIN Tolerance 1 1 - 255 GAIN Tolerance
22 Image Level Tolerance 3 1 - 255 Image Level Tolerance
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
