Sanyo PLV-Z3000 Service Manual

- 69 -
No. Adjustment Item Initial Value Range Input source / Description
Group:500 CONPOSITE (NTSC)
1 Disp Dots 698 0 - 4095
2 H Back Porch 11 0 - 4095
3 V Back Porch 8 0 - 4095
4 Disp Line 478 0 - 4095
Group:501 CONPOSITE (PAL)
1 Disp Dots 690 0 - 4095
2 H Back Porch 18 0 - 4095
3 V Back Porch 10 0 - 4095
4 Disp Line 560 0 - 4095
Group:502 CONPOSITE (SECAM)
1 Disp Dots 688 0 - 4095
2 H Back Porch 15 0 - 4095
3 V Back Porch 6 0 - 4095
4 Disp Line 568 0 - 4095
Group:510 SCART (480i)
1 Disp Dots 688 0 - 4095
2 H Back Porch 124 0 - 4095
3 V Back Porch 40 0 - 4095
4 Disp Line 464 0 - 4095
Group:511 SCART (575i)
1 Disp Dots 672 0 - 4095
2 H Back Porch 147 0 - 4095
3 V Back Porch 52 0 - 4095
4 Disp Line 548 0 - 4095
Group : 520 YCbCr (480i)
0 Total Dots 858 0 - 4095
1 Disp Dots 702 0 - 4095
2 H Back Porch 129 0 - 4095
3 V Back Porch 31 0 - 4095
4 Disp Line 481 0 - 4095
Group : 521 YCbCr (575i)
0 Total Dots 864 0 - 4095
1 Disp Dots 688 0 - 4095
2 H Back Porch 145 0 - 4095
3 V Back Porch 44 0 - 4095
4 Disp Line 570 0 - 4095
Group : 522 YCbCr (480P)
0 Total Dots 858 0 - 4095
1 Disp Dots 714 0 - 4095
2 H Back Porch 124 0 - 4095
3 V Back Porch 34 0 - 4095
4 Disp Line 483 0 - 4095
Group : 523 YCbCr (575P)
0 Total Dots 864 0 - 4095
1 Disp Dots 714 0 - 4095
2 H Back Porch 134 0 - 4095
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
