Sanyo PLV-Z3000 Service Manual

- 70 -
No. Adjustment Item Initial Value Range Input source / Description
3 V Back Porch 42 0 - 4095
4 Disp Line 576 0 - 4095
Group : 524 YCbCr (720P - 60)
0 Total Dots 1650 0 - 4095
1 Disp Dots 1280 0 - 4095
2 H Back Porch 297 0 - 4095
3 V Back Porch 23 0 - 4095
4 Disp Line 720 0 - 4095
Group : 525 YCbCr (720P - 50)
0 Total Dots 1980 0 - 4095
1 Disp Dots 1280 0 - 4095
2 H Back Porch 296 0 - 4095
3 V Back Porch 25 0 - 4095
4 Disp Line 720 0 - 4095
Group : 526 YCbCr (1080i - 60)
0 Total Dots 2200 0 - 4095
1 Disp Dots 1920 0 - 4095
2 H Back Porch 233 0 - 4095
3 V Back Porch 36 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 527 YCbCr (1080i - 50)
0 Total Dots 2640 0 - 4095
1 Disp Dots 1920 0 - 4095
2 H Back Porch 233 0 - 4095
3 V Back Porch 36 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 529 YCbCr (1080P - 60)
0 Total Dots 2200 0 - 4095
Before adjustment : The data of Total dots, Disp dots, and H
Back Porch is individually written.
Step 1: No.0 "Total dots data" After it does of+2, it return.
Step 2: No.1 "Dips dots data" After it does of+2, it return.
Step 3: No.2 "H back porch" After it does of+2, it return.
1 Disp Dots 1920 0 - 4095
2 H Back Porch 231 0 - 4095
3 V Back Porch 38 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 530 YCbCr (1080P - 50)
0 Total Dots 2640 0 - 4095
Before adjustment : The data of Total dots, Disp dots, and H
Back Porch is individually written.
Step 1: No.0 "Total dots data" After it does of+2, it return.
Step 2: No.1 "Dips dots data" After it does of+2, it return.
Step 3: No.2 "H back porch" After it does of+2, it return.
1 Disp Dots 1920 0 - 4095
2 H Back Porch 231 0 - 4095
3 V Back Porch 38 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 540 RGB Video (480i)
0 Total Dots 956 0 - 4095
1 Disp Dots 784 0 - 4095
2 H Back Porch 167 0 - 4095
3 V Back Porch 40 0 - 4095
4 Disp Line 484 0 - 4095
Group : 541 RGB Video (575i)
0 Total Dots 958 0 - 4095
1 Disp Dots 768 0 - 4095
2 H Back Porch 184 0 - 4095
Electrical Adjustments

Sanyo PLV-Z3000 Specifications

General

Matrix size	0.7 \
Vertical scan range	50 - 100 Hz
Horizontal scan range	15 - 80 kHz
Projection technology	LCD
Contrast ratio (typical)	-
Screen size compatibility	40 - 300 \
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 146 x 346 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Focus	Manual
Focal length range	22.3 - 45.3 mm
Noise level	19 dB
Dot clock scanning frequency	100 MHz
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	3

Weight and Dimensions

Weight	7500 g
