Sanyo PLV-Z3000 Service Manual

- 71 -
No. Adjustment Item Initial Value Range Input source / Description
3 V Back Porch 48 0 - 4095
4 Disp Line 570 0 - 4095
Group : 543 RGB Video (575P)
0 Total Dots 984 0 - 4095
1 Disp Dots 812 0 - 4095
2 H Back Porch 153 0 - 4095
3 V Back Porch 49 0 - 4095
4 Disp Line 576 0 - 4095
Group : 544 RGB Video (720P - 60)
0 Total Dots 1650 0 - 4095
1 Disp Dots 1280 0 - 4095
2 H Back Porch 298 0 - 4095
3 V Back Porch 25 0 - 4095
4 Disp Line 720 0 - 4095
Group : 545 RGB Video (720P - 50)
0 Total Dots 1980 0 - 4095
1 Disp Dots 1280 0 - 4095
2 H Back Porch 296 0 - 4095
3 V Back Porch 25 0 - 4095
4 Disp Line 720 0 - 4095
Group : 546 RGB Video (1080i - 60
0 Total Dots 2200 0 - 4095
1 Disp Dots 1920 0 - 4095
2 H Back Porch 234 0 - 4095
3 V Back Porch 40 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 547 RGB Video (1080i - 50)
0 Total Dots 2640 0 - 4095
1 Disp Dots 1920 0 - 4095
2 H Back Porch 233 0 - 4095
3 V Back Porch 40 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 549 RGB Video (1080P - 60)
0 Total Dots 2200 0 - 4095
Before adjustment : The data of Total dots, Disp dots, and H
Back Porch is individually written.
Step 1: No.0 "Total dots data" After it does of+2, it return.
Step 2: No.1 "Dips dots data" After it does of+2, it return.
Step 3: No.2 "H back porch" After it does of+2, it return.
1 Disp Dots 1920 0 - 4095
2 H Back Porch 230 0 - 4095
3 V Back Porch 41 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 550 RGB Video (1080P - 50)
0 Total Dots 2640 0 - 4095
Before adjustment : The data of Total dots, Disp dots, and H
Back Porch is individually written.
Step 1: No.0 "Total dots data" After it does of+2, it return.
Step 2: No.1 "Dips dots data" After it does of+2, it return.
Step 3: No.2 "H back porch" After it does of+2, it return.
1 Disp Dots 1920 0 - 4095
2 H Back Porch 229 0 - 4095
3 V Back Porch 41 0 - 4095
4 Disp Line 1080 0 - 4095
Group : 551 RGB Video (1080P - 30)
0 Total Dots 2200 0 - 4095
1 Disp Dots 1920 0 - 4095
2 H Back Porch 234 0 - 4095
Electrical Adjustments
