74 Operating Instructions Cubis
®
MCA
System Settings
7.7.13 Parameters in the “Connections / Interfaces / USB-B Interface” Menu
Parameter Setting Values Explanation
Protocol Off* Deactivates the USB-B connection.
SBI Enables SBI communication. The data is output to a PC or control
unit. Enables the use of ESC commands from a PC to control the
basic balance functions with ASCII protocol.
SICS Enables SICS communication. The data is output to a PC or control
unit. Enables the use of commands from a PC to control the basic
balance functions with SICS protocol.
xBPI Extended range of commands to control numerous balance
functions with binary protocol for direct communication with the
weighing module.
PC direct Enables data output to a spreadsheet program via a direct
PCconnection.
QAPP direct Enables data entry and output to a data processing program via
aQAPP direct connection. Only the special QAPPs, which are
started by a task, can use the interface for their purposes of input
and output.
miniSICS Enables miniSICS communication. The data is output to a PC or
control unit. Enables the use of commands from a PC to control
the basic balance functions with the miniSICS protocol.
Log
communication
On Activates the automatic data recording for this interface
(onlyactivate for test purposes).
Off* Deactivates the automatic data recording for this interface.
* Factory setting
