Tare Memory, Calculated Values:
The symbols displayed here indicate
when there is a value in one of the tare
memory modules or when the value
shown is a result of calculation rather
than direct measurement.
These symbols are as follows:
a Calculated value
s
1 Tare memory used by an
s
2 Application program
(e.g., formulation, second tare)
Application Pictograms:
The pictograms displayed here
indicate the application(s) selected.
The pictogram is displayed inversely
when the corresponding application
is active.
For example, the following symbols
may be displayed simultaneously:
A The counting application is
active
H Checkweighing is also active
S Print
T Data record
Text Line:
Additional information is displayed
here (e.g., operator guidance prompts,
name of the active program, etc.).
Soft Key Labels:
The current functions of the soft keys
are indicated here; during calibration/
adjustment, this line shows up- and
down-arrows (
Q and q) for selecting
calibration and adjustment functions.
Display for Menu Parameter Settings
(Setup)
This display is divided into three
sections.
Header
The header indicates the function of
the current screen page. In the Setup
program, the current menu path is
shown here.
Example in the path “Setup/Menu”:
Input and Output Window
This window contains either detailed
information (e.g., on the active
application) or a pick list. A selected
item is displayed inversely. You can also
enter information in an active field in
this window using the alphanumeric
keys.
Example in the path “Setup/Menu”:
The
o symbol in this window indicates
the current menu setting.
Soft Key ID Labels:
see “Function Keys (Soft Keys)” on
the previous page.
1 Minimum vibration
o 2 Normal vibration
3 Strong vibration
4 Extreme vibration
SETUP MENU [ ]
Header
Input and Output Window
Footer
To select a parameter:
§ Press
Q or q repeatedly until the
desired setting is selected (displayed
inversely)
§ Confirm your selection by pressing
the
l soft key
To change the alphanumeric value
of a parameter:
§ Press
Q or q repeatedly until the
desired setting is selected (displayed
inversely)
§ Enter the desired character using the
0 1 … 9 . keys or press the
a key and enter letters or characters
§ Confirm your selection by pressing
the
l soft key
To return to the Setup/Menu level:
§ Press the
oo soft key
5
