HINTS ON THE PARAMETER LEVEL
Filter time constant t_F
Adjust the filter time constant to the time, at which the signal variation is acceptable.
Filter bandwidth b_F
The bandwith is the adjustable tolerance in which the filter is active. Changes of the
process value larger than the adjusted bandwith are not filtered and will be transferred
directly to the output.
Example:Signal variations are e.g. +/- 1,5 mV. The filter bandwidth must be adjusted
directly to this variation.Enter: 1.5
9408-800-25001 11
Fig.: 2
Fig.: 3
Filter bandwitdth
