SARTORIUS RC/MC-Balances
27
RC-F-42.TIF
RC-F-40.TIF
RC-F-54.TIF
Cleaning
Cleaning the Weighing System
Important Note: Cleaning is necessary only if the reproducibility of the weighing results is
poor!
Opening the Weighing System
– Remove the screws (A1) from the side of the shield cover (301) and
carefully lift off the cover.
– Carefully unscrew the small cover disk (A2).
– Remove the 4 screws (A3).
– Remove the magnet cover plate straight up without tilting it.
Warning!
Tilting can cause damage to the magnet cover plate.
Checking and Cleaning the Weighing System
– Carefully check to make sure that the gap around the coil is clean.
– Remove any small bits of debris or fuzz by carefully sliding adhesive tape
through the gap.
– Check to make sure that the base plate is clean and carefully remove any
dirt.
Closing the Weighing System
– Carefully reposition the magnet cover plate (A4), aligning it with respect
to the transport pin (A5) so that the clearance around the coil is uniform.
– Fasten the 4 screws (A3) back on; then cover the drill hole with a new
cover disk (A2) (can also be ordered as an accessory).
– Replace the shield cover (301) by pressing down on it and securely fasten
in place.
– Proceed as described in the section “Closing the Balance Housing”.
A1
A3
A2
