SARTORIUS RC/MC-Balances
17
RC-A-19.TIF
RC-A-12.TIF
RC-li-02.TIF
RC-li-03.TIF
RC-A-34.TIF
Linearity
Checking the Linearity:
Important note: Check the linearity as described in the section “Checking the Linearity” on
page 12).
External Linearity Adjustment
The RC-/MC-balance can be linearized in different ways:
1. the way explained in this service manual;
2. using the PSION server; or
3. using the SARTOCAS program for personal computers and laptops.
Only use the PSION server or the SARTOCAS program to adjust the linearity
of this balance (Linearity adjustment with "UNKNOWN WEIGHTS").
Minor linearity deviations (no "S"-linearity) can be adjusted using the internal
linearity program of the balance.
Only in exceptional cases (e.g. no service software available) the MC-
balances may be linearized using the internal linearization program.
The RC-balances should not be linearized with the internal inearization
program!
Internal Linearity Adjustment
– Make sure the balance operating menu is set to code “ 1 13 1 “
- internal linearization accessible - .
– At 0,00000 g display press the key (MC) or the key (RC) and
keep it pressed (for at least 3 sec.) until the readout on the left is
displayed.
– Press the key until “ L.i. “ is displayed.
– Tare the balance by pressing the key (MC) or the key (RC) and
press the key to start the linearization routine.
– The build-in weights are internally applied by servomotor and removed at
the end of linearization.
– After finishing the linearization routine the linearity has to be checked
externally again (see page 12 "Checking the Linearity").
