Setup and Configuration PR 5210 Operating Manual
24 Sartorius
4.7.2 Weighing point configuration
4.7.2.1 Overload
Entry is in d, maximum permissible range 0d to 9999999d, default = 9d
Weight values above FSD + overload are generating an error message. The overload range prevents the
scale from going into error condition in case that the weight is only some digits above the FSD range.
For 'legal for trade' applications this value must not be greater than 9e.
4.7.2.2 Filter
Select between none or Bessel, Aperiodic, Butterworth. The digital filter (low-pass, 4-th order) is
located behind the ADC, in intervals of the measuring rate a new value is calculated.
With digital filter activated, the cutoff frequency (see chapter 4.7.2.3 ) has to be defined. Weight
values to be displayed are generated behind the digital filter.
• After changing the filter parameters, the maximum accuracy should be reestablished by re-
calibration.
4.7.2.3 Frequency
The range of the filter cutoff frequency is depending on the measuring rate (see table), it is only used
if the filter is not set to none!
Measuring rate Min. frequency Max. frequency
10 ms 0.25 Hz 1.84 Hz
20 ms 0.12 Hz 1.98 Hz
40 ms 0.06 Hz 1.83 Hz
80 ms 0.03 Hz 1.97 Hz
160 ms 0.02 Hz 1.56 Hz
over 160 ms 0.02 Hz 1.56 Hz
4.7.2.4 Measuring time
The measuring time is the time at which a weight value is measured.
Enter 10 to 1920ms, default = 320 ms.
Up to 160 ms the measuring time equates the conversion time for the internal ADC.
Over 160 ms the conversion time for the internal ADC remains on 160 ms, but the average weight is
presented in the given time.
4.7.2.5 Weight & Measure
Select Weight & Measure: 'off' or 'on' = OIML.
If
Weight & Measure ('legal for trade') is set to on, parameters are not automatically set to fulfill the
requirements! Please refer to the EN 45501 and the Type-approval Certificate.
The Weight & Measure mode has to be set before a calibration is started.
Default is off.
