PR 5210 Operating Manual Profibus Interface
Sartorius 45
6.1.5 Register read and write via Profibus
6.1.5.1 Data read: Read_Value, Read_Value_Select, Read_Value_Selected
If the master shall read from the transmitter, then the register number ins transferred in
Read_Value_Select in the input area. The result will be indicated in the output area with
Read_Value_Selected .
Master Transmitter
Write registerno. to Read_Value_Select
Write selected register in Read_Value
Copy Read_Value_Select to
Read_Value_Selected
Wait until
Read_Value_Selected = Read_Value_Select
Read Read_Value
6.1.5.2 Write data: Write_Value, Write_Value_Select, Write_Active
If the master shall write to the transmitter, then the required action will be transferred with
Write_Value_Select together with the data in the input area. The execution will be indicated
with the bit Write_Active in the output area.
Master action Transmitter action
Write value in Write_Value
Register number in Write_Value_Select
Write Write_Value to selected register
Set bit Write_Active
Wait until Write_Active is set
Write 0 in Write_Value_Select
Reset bit Write_Active
6.1.5.3 Set / reset bit: Write_Value_Select, Write_Active
Single bits can be set or reset directly with Write_Value_Select .
To set, the bit number (80.. 127) is written to Write_Value_Select.
To reset, the bit number + 128 (208..255) is written to Write_Value_Select.
The Write_Value itself is not relevant.
Master Transmitter
Register number in Write_Value_Select
Write Write_Value to selected register
Set bit Write_Active
Wait until Write_Active is set
Write 0 in Write_Value_Select
Reset bit Write_Active
