Satec PM172E Reference Guide

64
Address Point ID Description Options/Range Units Type R/W Notes
47072-47075 V1 transformer correction
47076-47079 V2 transformer correction
47080-47083 V3 transformer correction
47084-47087 Reserved
47088-47091 I1 transformer correction
47092-47095 I2 transformer correction
47096-47099 I3 transformer correction
EGD Producer Exchanges Setup
50454-50837
+0-1 Exchange consumer IP Address 0x01000000-0xFFFFFFFF UINT32 R/W Network byte order
+2 Production interval 1-60000
×10 ms
UINT16 R/W
+3 Exchange status 0=disabled, 1=enabled UINT16 R/W
+4,5 Reserved 0 UINT16 R/W
+6 Address range #1: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+7 Address range #1: End point ID 1-65535 UINT16 R/W
+8 Address range #1: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
+9 Address range #2: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+10 Address range #2: End point ID 1-65535 UINT16 R/W
+11 Address range #2: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
… R/W
+93 Address range #30: Start point ID 0-65535, 0=end of the range list UINT16 R/W
+94 Address range #30: End point ID 1-65535 UINT16 R/W
+95 Address range #30: Data type 0=Word, 1=DWord, 2= Float UINT16 R/W
50454-50549 Exchange #1
50550-50645 Exchange #2
50646-50741 Exchange #3
50742-50837 Exchange #4
DNP Options Setup
51158-51183
+0 Binary Input Static Objects F24 (default 0) UINT16 R/W
+1 Binary Input Change Objects F24 (default 1) UINT16 R/W
+2 Binary Counter Objects F24 (default 3) UINT16 R/W
+3 Frozen Binary Counter Objects F24 (default 4) UINT16 R/W
+4 Reserved UINT16 R/W
+5 Binary Counter Change Event Objects F24 (default 2) UINT16 R/W
+6 Analog Input Objects F24 (default 3) UINT16 R/W
+7 Reserved UINT16 R/W
+8 Reserved UINT16 R/W
+9 Analog Input Change Event Objects F24 (default 2) UINT16 R/W
+10 Re-mapping static point indices for event objects 0=disabled (default), 1=enabled UINT16 R/W
+11 16-bit BC Scaling
0=×1 (default), 1=×10, 2=×100,
3=×1000
UINT16 R/W
+12 16-bit AI Scaling 0 – scaling OFF, 1-scaling ON UINT16 R/W
