Satec PM172E Reference Guide

31
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
9456-9463 Summary Energy Sliding Window Demands
E
+0 0x4600
Summary register #1 demand
0-Pmax U3 UINT16 R
+1 0x4601
Summary register #2 demand
0-Pmax U3 UINT16 R
… R
+7 0x4607
Summary register #8 demand
0-Pmax U3 UINT16 R
9516-9523 Summary Energy Maximum Demands
E
+0 0x4780
Summary register #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4781
Summary register #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4787
Summary register #8 maximum demand
0-Pmax U3 UINT16 R
9536-9543 TOU Maximum Demand Register #1
E
+0 0x4800
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4801
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4807
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9576-9583 TOU Maximum Demand Register #2
E
+0 0x4900
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4901
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4907
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9616-9623 TOU Maximum Demand Register #3
E
+0 0x4A00
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4A01
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4A07
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9556-9563 TOU Maximum Demand Register #4
E
+0 0x4880
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4881
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4887
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9596-9603 TOU Maximum Demand Register #5
E
+0 0x4980
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4981
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4987
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
9636-9643 TOU Maximum Demand Register #6
E
+0 0x4A80
Tariff #1 maximum demand
0-Pmax U3 UINT16 R
+1 0x4A81
Tariff #2 maximum demand
0-Pmax U3 UINT16 R
… R
+7 0x4A87
Tariff #8 maximum demand
0-Pmax U3 UINT16 R
