85
Format Code Value Description Notes
0x0000-0x59FF Trigger parameter ID
0x6400-0xFFFF Trigger parameter ID
Setpoint Action Events
0x5A00-0x5A0F Setpoint #1-#16
Communications Events
0x5B00-0x5BFF Data point ID (low byte, see F21)
Front Panel Operations
0x5C00-0x5CFF Data point ID (low byte, see F21)
Self-Check Diagnostics Events
0x5D00-0x5DFF Data point ID (low byte, see F21)
Self-Update Events
0x5E08 RTC DST/Standard time update
Hardware Diagnostics Events
0x6202 RAM/Data error
0x6203 Hardware watchdog reset
0x6204 Sampling fault
0x6205 CPU exception
0x6206 Reserved
0x6207 Software watchdog reset
0x620D Low battery
0x620F EEPROM fault
External Events
0x6300 Power down
0x6308 Power up
0x6309 External reset
Event Effect ID
Communications/Self-check/Front Panel Events
0x0000 None
0x6000 Total energy registers cleared
0x6100 All total maximum demands cleared
0x6101 Power maximum demands cleared
0x6102 Volt/Ampere/Harmonic maximum demands cleared
0x6200 Summary/TOU energy registers cleared
0x6300 Summary/TOU maximum demand registers cleared
0x6400 All counters cleared
0x6401-0x6403 Counter cleared (low byte = counter ID)
0x6500 Min/Max log cleared
0x6600 Event log file cleared (low byte = File ID)
0x6700-0x6707 Data log file cleared (low byte = File ID)
0x6710 All data logs cleared
0x6800 Waveform log #1 file cleared
0x6900 Waveform log #2 file cleared
0xF100-0xF10F Setpoint cleared (low byte = setpoint ID)
0xF200 Setup/Data cleared
0xF300 Setup reset (set by default)
0xF400 Setup changed
0xF500 RTC set
Setpoint Operation Events
0xE100-0xE10F Setpoint operated (low byte = setpoint ID)
0xE200-0xE20F Setpoint released (low byte = setpoint ID)
Setpoint Action Events
F20
See F14 Setpoint action ID
Data Point ID
Data Locations
0x03 Data memory
0x04 Factory setup
0x05 Access/Password setup
0x06 Basic setup
0x07 Communications setup
0x08 Real-time clock
0x09 Digital inputs setup
0x0A Pulse counters setup
0x0B AO setup
0x0E Timers setup
0x10 Event/alarm setpoints
0x11 Pulsing setup
F21
0x12 User assignable register map
