Satec PM172E Reference Guide
5
of 1
of 1 rating
88 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
69
Address Point
ID
Description
Opti
ons/Range Units
Type
R/W
Notes
+4,5
Full scale val
ue (20/1 mA)
INT32
R/W
62368-62373
AI1 Setup
62374-62379
AI2 Setup
Analog Outputs Setup
62560-62571
+0
Output parameter ID
F
18
UINT16
R/W
+1
Not
used
0
UINT16
R/W
+2,3
Zero scale value (0/4 mA)
See Section 3.4
INT32
R/W
+4,5
Full scale val
ue (20/1 mA)
See Section 3.4
INT32
R/W
62560-62565
AO1 Setup
62566-62571
AO2 Setup
68
70
Table of Contents
Default Chapter
3
Table of Contents
3
General
8
Modbus Protocol Implementation
9
Transmission Modes
9
Address Field
9
Function Field
9
Exception Responses
9
Modbus Register Addresses
9
Data Formats
10
16-Bit Scaled Integer Format
10
32-Bit Long Integer Format
11
32-Bit Modulo-10000 Format
12
User Assignable Registers
12
Password Protection
12
Data Recording and File Transfers
13
Log File Organization
13
Multi-Section Files
13
Data Log Files
13
Profile Data Log File
14
Waveform Log Files
14
File Transfers
14
Common File Transfer
14
Reading a Profile Log File
15
Reading Waveform Files
15
Reading Real-Time Waveforms
16
TCP Notification Client
16
Modbus Register Map
18
Modbus Setup Registers
18
Modbus Assignable Registers
18
Assignable Registers Map
18
Modbus Conversion Scales
18
Device Data Scales
18
16-Bit Scaled Analog Registers and Energy Counters - Basic Register Set
19
16-Bit Scaled Analog Registers, Binary Registers and Counters
21
None
21
Special Inputs
21
Event Flags (Bitmap) Digital Inputs (Bitmap)
21
Relay Outputs (Bitmap)
21
Counters
21
1-Cycle Phase Values
21
1-Cycle Total Values
22
1-Cycle Auxiliary Values
22
Phasor
22
1-Second Phase Values
23
1-Second Total Values
23
1-Second Auxiliary Values
24
Present Harmonic Demands
24
Present Volt, Ampere and Power Demands
24
Total Energies
25
Phase Energies
25
V1/V12 Harmonic Distortions
25
V3/V31 Harmonic Distortions
26
I1 Harmonic Distortions
26
I2 Harmonic Distortions
26
I3 Harmonic Distortions
26
Fundamental (H01) Phase Values
26
Harmonic Total Values
27
Minimum 1-Cycle Phase Values
27
Minimum 1-Cycle Total Values
27
Minimum 1-Cycle Auxiliary Values
27
Maximum 1-Cycle Phase Values
28
Maximum 1-Cycle Total Values
28
Maximum 1-Cycle Auxiliary Values
28
Maximum Demands
28
Maximum Harmonic Demands
29
Scaled Analog Inputs
29
Raw Analog Inputs
29
TOU Parameters
29
Scaled Analog Outputs
29
TOU Energy Register #1
29
TOU Energy Register #2
29
TOU Energy Register #3
30
TOU Energy Register #4
30
TOU Energy Register #5
30
TOU Energy Register #6
30
TOU Energy Register #7
30
TOU Energy Register #8
30
Summary Energy Accumulated Demands
30
Summary Energy Block Demands
30
Summary Energy Sliding Window Demands
31
Summary Energy Maximum Demands
31
TOU Maximum Demand Register #1
31
TOU Maximum Demand Register #2
31
TOU Maximum Demand Register #3
31
TOU Maximum Demand Register #4
31
TOU Maximum Demand Register #5
31
TOU Maximum Demand Register #6
31
TOU Maximum Demand Register #7
32
TOU Maximum Demand Register #8
32
V1/V12 Harmonic Angles
32
V2/V23 Harmonic Angles
32
V1/V31 Harmonic Angles
32
I1 Harmonic Angles
32
I2 Harmonic Angles
32
I3 Harmonic Angles
32
Setpoint Status (Bitmap)
33
32-Bit Analog Registers, Binary Registers and Counters
34
Special Inputs
34
Event Flags (Bitmap)
34
Digital Inputs DI1-DI2 (Bitmap)
34
Relay Outputs RO1-RO2 (Bitmap)
34
Counters
34
1-Cycle Phase Values
34
1-Cycle Total Values
35
1-Cycle Auxiliary Values
35
Phasor
35
1-Second Phase Values
36
1-Second Total Values
36
1-Second Auxiliary Values
37
Present Harmonic Demands
37
Present Volt, Ampere and Power Demands
37
Total Energies
38
Summary Energy Registers
38
Phase Energies
38
V1/V12 Harmonic Distortions
39
V2/V23 Harmonic Distortions
39
V3/V31 Harmonic Distortions
39
I1 Harmonic Distortions
39
I2 Harmonic Distortions
39
I3 Harmonic Distortions
39
Fundamental (H01) Phase Values
39
Harmonic Total Values
40
Minimum 1-Cycle Phase Values
40
Minimum 1-Cycle Total Values
40
Minimum 1-Cycle Auxiliary Values
41
Maximum 1-Cycle Phase Values
41
Maximum 1-Cycle Total Values
41
Maximum 1-Cycle Auxiliary Values
41
Maximum Demands
41
Maximum Harmonic Demands
42
Scaled Analog Inputs
42
Raw Analog Inputs
42
TOU Parameters
42
Scaled Analog Outputs
42
TOU Energy Register #1
42
TOU Energy Register #2
43
TOU Energy Register #3
43
TOU Energy Register #4
43
TOU Energy Register #5
43
TOU Energy Register #6
43
TOU Energy Register #7
43
TOU Energy Register #8
43
Summary Energy Accumulated Demands
43
Summary Energy Block Demands
44
Summary Energy Sliding Window Demands
44
Summary Energy Maximum Demands
44
TOU Maximum Demand Register #1
44
TOU Maximum Demand Register #2
44
TOU Maximum Demand Register #3
44
TOU Maximum Demand Register #4
44
TOU Maximum Demand Register #5
44
TOU Maximum Demand Register #6
45
TOU Maximum Demand Register #7
45
TOU Maximum Demand Register #8
45
V1/V12 Harmonic Angles
45
V2/V23 Harmonic Angles
45
V1/V31 Harmonic Angles
45
I1 Harmonic Angles
45
I2 Harmonic Angles
45
I3 Harmonic Angles
45
Generic TOU Season Energy Registers ID's
46
Generic TOU Season Maximum Demand Registers ID's
46
Setpoint Status SP1-SP16 (Bitmap)
46
Minimum/Maximum Log Registers
46
Minimum Phase Values
46
Minimum Total Values
47
Minimum Auxiliary Values
47
Maximum Phase Values
48
Maximum Total Values
48
Maximum Auxiliary Values
49
Summary Energy Maximum Demands
49
Maximum Demands
49
Maximum Harmonic Demands
50
TOU Maximum Demand Register #1
50
TOU Maximum Demand Register #2
50
TOU Maximum Demand Register #3
51
TOU Maximum Demand Register #4
51
TOU Maximum Demand Register #5
51
TOU Maximum Demand Register #6
51
TOU Maximum Demand Register #7
51
TOU Maximum Demand Register #8
52
Device Control and Status Registers
53
Device Restart Register
53
Device Authorization Registers
53
Event Flags Control
53
Remote Relay Control
53
Device Reset/Clear Registers
53
Device Identification
54
Device Status Registers
54
Log Notification Registers
54
Alarm Notification Registers
54
Communication Status
55
Communication Counters
55
Device Setup Registers
56
Device Identification
56
Factory Device Settings
56
Basic Setup
56
Communication Ports Setup
57
Device Options Setup
58
Local Settings
58
Clock Indication and Setup
59
Alarm/Event Setpoints Setup
59
Data Log Setup
60
Pulse Counters Setup
61
Analog Outputs Setup
61
Analog Expander Setup
61
Digital Inputs Setup
62
Periodic Timers Setup
62
File Setup
62
Network Setup
62
Password Setup
63
Expert Power Service Setup
63
Internet Service Provider (ISP) Accounts
63
GPRS Setup
63
TCP Notification Client Setup
63
Transformer Correction Setup
63
EGD Producer Exchanges Setup
64
DNP Options Setup
64
DNP Events Setup
65
DNP Class 0 Point Assignments
65
Waveform Recorder Setup
66
TOU Daily Profile Setup
66
TOU Calendar Setup
67
Summary Energy/Tou Registers Setup
67
Summary Energy/Tou Registers Source Setup
68
Digital Inputs Setup
68
Relay Outputs Setup
68
Analog Inputs Setup
68
Analog Outputs Setup
69
Analog and Digital I/O Configuration
70
I/O Slots Configuration Info
70
I/O Type Info
70
File Transfer Registers
71
File Allocation Status Registers
71
File Transfer Control/Status Registers
71
Event Log File Transfer Registers
73
Data Log File Transfer Registers
73
Waveform Header Transfer Registers
75
Waveform Series Transfer Block
76
Billing/Tou Daily Profile Data Log
77
Data Scales and Units
79
Data Scales
79
Data Units
79
Data Formats
80
Timestamp
80
Wiring Mode
80
File Attributes
80
File Status Word
80
File Record Status Word
80
File Allocation Map
80
Profile Log Sections Map
80
Waveform Log Channel Mask
80
TOU Tariff Change Time
80
Summary/Tou Energy Register Source ID
81
Setpoint Trigger Parameters ID
81
Pulse Inputs
81
Relays
81
Setpoint Action ID
83
Counter Source ID
84
Relay Output Pulse Source ID
84
Ao/Analog Expander Output Parameters ID
84
Event Cause/Point ID
84
Event Effect ID
85
Data Point ID
85
Device Diagnostics
86
DNP Object Types
86
DNP Class 0 Objects
87
Log Notification Status
87
Data Log Notification Status
87
Instrument Options
87
I/O Slot Types
87
