Satec PM172E Reference Guide

44
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+14,15 0x4507
Summary register #8 demand
0-Pmax U3 UINT32 R
20648-20663 Summary Energy Block Demands
E
+0,1 0x4580
Summary register #1 demand
0-Pmax U3 UINT32 R
+2,3 0x4581
Summary register #2 demand
0-Pmax U3 UINT32 R
…
+14,15 0x4587
Summary register #8 demand
0-Pmax U3 UINT32 R
20736-20751 Summary Energy Sliding Window Demands
E
+0,1 0x4600
Summary register #1 demand
0-Pmax U3 UINT32 R
+2,3 0x4601
Summary register #2 demand
0-Pmax U3 UINT32 R
…
+14,15 0x4607
Summary register #8 demand
0-Pmax U3 UINT32 R
20904-20919 Summary Energy Maximum Demands
E
+0,1 0x4780
Summary register #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4781
Summary register #2 maximum demand
0-Pmax U3 UINT32 R
…
+14,15 0x4787
Summary register #8 maximum demand
0-Pmax U3 UINT32 R
20992-21023 TOU Maximum Demand Register #1
E
+0,1 0x4800
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4801
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4807
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21120-21135 TOU Maximum Demand Register #2
E
+0,1 0x4900
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4901
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4907
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21248-21263 TOU Maximum Demand Register #3
E
+0,1 0x4A00
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4A01
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4A07
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21032-21047 TOU Maximum Demand Register #4
E
+0,1 0x4880
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4881
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4887
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
21160-21175 TOU Maximum Demand Register #5
E
+0,1 0x4980
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4981
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4987
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
