Satec PM172E Reference Guide

68
Address Point ID Description Options/Range Units Type R/W Notes
56696-56699 Register #7 Setup
56700-56703 Register #8 Setup
Summary Energy/TOU Registers Source Setup
E
56928-57183
+0 Energy source ID F11 UINT16 R/W
+1 Target summary register number 0-7 = register #1-#8 UINT16 R/W
+2,3 Multiplier 0-1000000
×0.001
INT32 R/W
56928-56931 Energy Source #1
56932-56935 Energy Source #2
56936-56939 Energy Source #3
56940-56943 Energy Source #4
56944-56947 Energy Source #5
56948-56951 Energy Source #6
56952-56955 Energy Source #7
56956-56959 Energy Source #8
Digital Inputs Setup
61728-61735
+0 Pulse mode 0 = pulse, 1 = KYZ UINT16 R/W
+1 Polarity 0 = normal, 1 = inverting UINT16 R/W
+2 De-bounce time, ms 1-1000 UINT16 R/W Debounce time will be the same for
both inputs
+3 Reserved UINT16 R/W
61728-61731 DI1 Setup
61732-61735 DI2 Setup
Relay Outputs Setup
61984-61995
+0 Operation Mode 0=unlatched, 1=latched,
2=pulse, 3=KYZ
UINT16 R/W
+1 Polarity Bit 0 – Polarity:
0=normal, 1=inverting,
Bit 1 - Retentive mode:
0=disabled, 1=enabled
UINT16 R/W
+2 Pulse width, ms 1-1000 UINT16 R/W
+3 Pulse source ID F17 UINT16 R/W
+4 Units per pulse 1-10000 x0.1 UINT16 R/W
+5 Reserved UINT16 R/W
61984-61989 RO1 Setup
61990-61995 RO2 Setup
Analog Inputs Setup
62368-62379
+0 Input parameter ID 0 = input not assigned UINT16 R/W
+1 Not used 0 UINT16 R/W
+2,3 Zero scale value (0/4 mA) INT32 R/W
