Satec PM172E Reference Guide

39
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
+14,15 0x1807 kVAh total L2 0-999,999,999 1 kVAh UINT32 R
+16,17 0x1808 kVAh total L3 0-999,999,999 1 kVAh UINT32 R
14976-15055 V1/V12 Harmonic Distortions
EH 1
+0,1 0x1900
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1901
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1927
H40 Harmonic distortion
0-10000 0.01% UINT32 R
15104-15183 V2/V23 Harmonic Distortions
EH 1
+0,1 0x1A00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1A01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1A27
H40 Harmonic distortion
0-10000 0.01% UINT32 R
15232-15311 V3/V31 Harmonic Distortions
EH 1
+0,1 0x1B00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1B01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1B27
H40 Harmonic distortion
0-10000 0.01% UINT32 R
15360-15439 I1 Harmonic Distortions
EH
+0,1 0x1C00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1C01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1C27
H40 Harmonic distortion
0-10000 0.01% UINT32 R
15488-15567 I2 Harmonic Distortions
EH
+0,1 0x1D00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1D01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1D27
H40 Harmonic distortion
0-10000 0.01% UINT32 R
15616-15695 I3 Harmonic Distortions
EH
+0,1 0x1E00
H01 Harmonic distortion
0-10000 0.01% UINT32 R
+2,3 0x1E01
H02 Harmonic distortion
0-10000 0.01% UINT32 R
...
+78,79 0x1E27
H40 Harmonic distortion
0-10000 0.01% UINT32 R
17024-17059 Fundamental (H01) Phase Values 4-cycle values
+0,1 0x2900 V1/V12 Voltage 0-Vmax U1 UINT32 R
1
+2,3 0x2901 V2/V23 Voltage 0-Vmax U1 UINT32 R
1
+4,5 0x2902 V3/V31 Voltage 0-Vmax U1 UINT32 R
1
+6,7 0x2903 I1 Current 0-Imax U2 UINT32 R
+8,9 0x2904 I2 Current 0-Imax U2 UINT32 R
+10,11 0x2905 I3 Current 0-Imax U2 UINT32 R
+12,13 0x2906 kW L1 -Pmax-Pmax U3 INT32 R
+14,15 0x2907 kW L2 -Pmax-Pmax U3 INT32 R
