Satec PM172E Reference Guide

22
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+26 0x0C1A I3 K-Factor 1.0-999.9 0.1 UINT16 R 4-cycle value
+27 0x0C1B I1 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+28 0x0C1C I2 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+29 0x0C1D I3 Current TDD 0-100.0 0.1% UINT16 R 4-cycle value
+30 0x0C1E V12 Voltage 0-Vmax U1 UINT16 R
+31 0x0C1F V23 Voltage 0-Vmax U1 UINT16 R
+32 0x0C20 V31 Voltage 0-Vmax U1 UINT16 R
7256-7359 1-Cycle Total Values
+0 0x0F00 Total kW -Pmax-Pmax U3 INT16 R
+1 0x0F01 Total kvar -Pmax-Pmax U3 INT16 R
+2 0x0F02 Total kVA 0-Pmax U3 UINT16 R
+3 0x0F03 Total PF -1.000-1.000 0.001 INT16 R
+4 0x0F04 Total PF lag 0-1.000 0.001 UINT16 R
+5 0x0F05 Total PF lead 0-1.000 0.001 UINT16 R
+5 0x0F06 Total kW import 0-Pmax U3 UINT32 R
+7 0x0F07 Total kW export 0-Pmax U3 UINT32 R
+8 0x0F08 Total kvar import 0-Pmax U3 UINT32 R
+9 0x0F09 Total kvar export 0-Pmax U3 UINT32 R
+10 0x0F0A 3-phase average L-N/L-L voltage 0-Vmax U1 UINT32 R
1
+11 0x0F0B 3-phase average L-L voltage 0-Vmax U1 UINT32 R
+12 0x0F0C 3-phase average current 0-Imax U2 UINT32 R
7296-7300 1-Cycle Auxiliary Values
+0 0x1000 Not used UINT16 R
+1 0x1001 In (neutral) Current 0-Imax U2 UINT16 R
+2 0x1002 Frequency 0-Fmax 0.01Hz UINT16 R
+3 0x1003 Voltage unbalance 0-300 % UINT16 R
+4 0x1004 Current unbalance 0-300 % UINT16 R
7316-7331 Phasor
+0 0x1080 V1/V12 Voltage magnitude 0-Vmax U1 UINT16 R
1
+1 0x1081 V2/V23 Voltage magnitude 0-Vmax U1 UINT16 R
1
+2 0x1082 V3/V31 Voltage magnitude 0-Vmax U1 UINT16 R
1
+3 0x1083 Not used UINT16 R
+4 0x1084 I1 Current magnitude 0-Imax U2 UINT16 R
+5 0x1085 I2 Current magnitude 0-Imax U2 UINT16 R
+5 0x1086 I3 Current magnitude 0-Imax U2 UINT16 R
+7 0x1087 Not used UINT16 R
+8 0x1088 V1/V12 Voltage angle -180.0-180.0 0.1º INT16 R
1
+9 0x1089 V2/V23 Voltage angle -180.0-180.0 0.1º INT16 R
1
+10 0x108A V3/V31 Voltage angle -180.0-180.0 0.1º INT16 R
1
+11 0x108B Not used INT16 R
+12 0x108C I1 Current angle -180.0-180.0 0.1º INT16 R
+13 0x108D I2 Current angle -180.0-180.0 0.1º INT16 R
+14 0x108E I3 Current angle -180.0-180.0 0.1º INT16 R
