Satec PM172E Reference Guide

79
4 Data Scales and Units
Code Condition Value/Range Notes
Data Scales
Vmax
Voltage scale
× PT Ratio, V
2
Imax
Current scale (2A/10A)
× CT Ratio = CT Primary current × 2, A
1, 3
Wiring 4LN3, 3LN3, 3BLN3
Vmax
× Imax × 3, W
4
Pmax
Wiring 4LL3, 3LL3, 3BLL3,
3OP2, 3OP3, 3DIR2
Vmax
× Imax × 2, W
Nominal frequency 25, 50
or 60 Hz
100 Hz Fmax
Nominal frequency 400Hz 500 Hz
+/-1mA
AImin = -AI full scale
× 2
AImax = AI full scale
× 2
0-20mA AImin = AI zero scale
AImax = AI full scale
4-20mA AImin = AI zero scale
AImax = AI full scale
AImin
AImax
0-1mA AImin = AI zero scale
AImax = AI full scale
Data Units
PT Ratio = 1 0.1V U1
PT Ratio > 1 1V
U2 0.01A
PT Ratio = 1 1W/Var/VA U3
PT Ratio > 1 1kW/kvar/kVA
1
CT Ratio = CT primary current/CT secondary current
2
The default Voltage scale is 144V (120V +20%) unless you changed it in your device through the Device Data Scale setup
registers (see Section 3.1) or via the supplemental PAS software.
3
The default Current scale is 2 × CT secondary current (1A or 5A depending on the order).
4
Pmax is rounded to whole kilowatts. With PT=1.0, if Pmax is greater than 9,999,000 W, it is truncated to 9,999,000 W.
