Satec PM172E Reference Guide

45
Address Point ID Description
Options/Range
2
Units
2
Type R/W Notes
21288-21303 TOU Maximum Demand Register #6
E
+0,1 0x4A80
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x4A81
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x4A87
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
22400-22415 TOU Maximum Demand Register #7
E
+0,1 0x5300
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x5301
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x5307
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
22440-22455 TOU Maximum Demand Register #8
E
+0,1 0x5380
Tariff #1 maximum demand
0-Pmax U3 UINT32 R
+2,3 0x5381
Tariff #2 maximum demand
0-Pmax U3 UINT32 R
… R
+14,15 0x5387
Tariff #8 maximum demand
0-Pmax U3 UINT32 R
24576-24655 V1/V12 Harmonic Angles
EH 1, 3
+0,1 0x6400
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6401
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6427
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
24704-24783 V2/V23 Harmonic Angles
EH 1, 3
+0,1 0x6500
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6501
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6527
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
24832-24911 V1/V31 Harmonic Angles
EH 1, 3
+0,1 0x6600
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6601
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6627
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
25088-25167 I1 Harmonic Angles
EH 3
+0,1 0x6800
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6801
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6827
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
25216-25295 I2 Harmonic Angles
EH 3
+0,1 0x6900
H01 Harmonic angle
-1800-1800
×0.1º
INT32 R
+2,3 0x6901
H02 Harmonic angle
-1800-1800
×0.1º
INT32 R
...
+78,79 0x6927
H40 Harmonic angle
-1800-1800
×0.1º
INT32 R
25344-25423 I3 Harmonic Angles
EH 3
