Satec PM172E Reference Guide

26
Address Point ID Description
Low and High Scales
2
Units
2
Type R/W Notes
+39 0x1927
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
7696-7735 V2/V23 Harmonic Distortions
EH 1
+0 0x1A00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1A01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+39 0x1A27
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
7736-7775 V3/V31 Harmonic Distortions
EH 1
+0 0x1B00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1B01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+39 0x1B27
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
7776-7815 I1 Harmonic Distortions
EH
+0 0x1C00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1C01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+39 0x1C27
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
7816-7855 I2 Harmonic Distortions
EH
+0 0x1D00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1D01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+39 0x1D27
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
7856-7895 I3 Harmonic Distortions
EH
+0 0x1E00
H01 Harmonic distortion
0-100.00 0.01% UINT16 R
+1 0x1E01
H02 Harmonic distortion
0-100.00 0.01% UINT16 R
...
+39 0x1E27
H40 Harmonic distortion
0-100.00 0.01% UINT16 R
8296-8313 Fundamental (H01) Phase Values 4-cycle values
+0 0x2900 V1/V12 Voltage 0-Vmax U1 UINT16 R
1
+1 0x2901 V2/V23 Voltage 0-Vmax U1 UINT16 R
1
+2 0x2902 V3/V31 Voltage 0-Vmax U1 UINT16 R
1
+3 0x2903 I1 Current 0-Imax U2 UINT16 R
+4 0x2904 I2 Current 0-Imax U2 UINT16 R
+5 0x2905 I3 Current 0-Imax U2 UINT16 R
+6 0x2906 kW L1 -Pmax-Pmax U3 INT16 R
+7 0x2907 kW L2 -Pmax-Pmax U3 INT16 R
+8 0x2908 kW L3 -Pmax-Pmax U3 INT16 R
+9 0x2909 kvar L1 -Pmax-Pmax U3 INT16 R
+10 0x290A kvar L2 -Pmax-Pmax U3 INT16 R
+11 0x290B kvar L3 -Pmax-Pmax U3 INT16 R
+12 0x290C kVA L1 0-Pmax U3 UINT16 R
+13 0x290D kVA L2 0-Pmax U3 UINT16 R
