Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+22,23 Timestamp sec UINT32 R
+24-71 0x2C06-
0x2C11
Not used 0 INT32 R
+72,73
+74,75
0x2C12 Min. V1/V12 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+76,77
+78,79
0x2C13 Min. V2/V23 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+80,81
+82,83
0x2C14 Min. V3/V31 Voltage THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+84,85
+86,87
0x2C15 Min. I1 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
1
4-cycle value
+88,89
+90,91
0x2C16 Min. I2 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+92,93
+94,95
0x2C17 Min. I3 Current THD
Timestamp
0-9999
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+96,97
+98,99
0x2C18 Min. I1 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+100,101
+102,103
0x2C19 Min. I2 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+104,105
+106,107
0x2C1A Min. I3 K-Factor
Timestamp
10-9999
×0.1
sec
UINT32
UINT32
R
R
4-cycle value
+108,109
+110,111
0x2C1B Min. I1 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+112,113
+114,115
0x2C1C Min. I2 Current TDD
Timestamp
0-1000
×0.1%
sec
UINT32
UINT32
R
R
4-cycle value
+116,117
+118,119
0x2C1D Min. I3 Current TDD
Timestamp
0-1000 x0.1%
sec
UINT32
UINT32
R
R
4-cycle value
36096-36111 Minimum Total Values
+0,1
+2,3
0x2D00 Min. Total kW
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
+4,5
+6,7
0x2D01 Min. Total kvar
Timestamp
-Pmax-Pmax U3
sec
INT32
UINT32
R
R
+8,9
+10,11
0x2D02 Min. Total kVA
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+12,13
+14,15
0x2D03 Min. Total PF
Timestamp
-1000-1000
×0.001
sec
INT32
UINT32
R
R
36352-36362 Minimum Auxiliary Values
+0,1
+2,3
0x2E00 Not used UINT32
UINT32
R
R
+4,5
+6,7
0x2E01 Min. In Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+8,9
+10,11
0x2E02 Min. Frequency
Timestamp
0-Fmax
×0.01Hz
sec
UINT32
UINT32
R
R
