Satec PM172E Reference Guide

49
Address Point ID Description
Options/Range/Format
2
Units
2
Type R/W Notes
+8,9
+10,11
0x3502 Max. Total kVA
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+12,13
+14,15
0x3503 Max. Total PF
Timestamp
-1000-1000
×0.001
sec
INT32
UINT32
R
R
37376-37387 Maximum Auxiliary Values
+0,1
+2,3
0x3600 Not used UINT32
UINT32
R
R
+4,5
+6,7
0x3601 Max. In Current
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+8,9
+10,11
0x3602 Max. Frequency
Timestamp
0-Fmax
×0.01Hz
sec
UINT32
UINT32
R
R
37504-37535 Summary Energy Maximum Demands
E
+0,1
+2,3
0x4780 Summary register #1 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
+4,5
+6,7
0x4781 Summary register #2 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
…
+28,29
+30,31
0x4783 Summary register #8 Maximum Demand
Timestamp
0-Pmax U3 UINT32 R
37632-37695 Maximum Demands
+0,1
+2,3
0x3700 V1/V12 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+4,5
+6,7
0x3701 V2/V23 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+8,9
+10,11
0x3702 V3/V31 Maximum volt demand
Timestamp
0-Vmax U1
sec
UINT32
UINT32
R
R
1
+12,13
+14,15
0x3703 I1 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+16,17
+18,19
0x3704 I2 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+20,21
+22,23
0x3705 I3 Maximum ampere demand
Timestamp
0-Imax U2
sec
UINT32
UINT32
R
R
+24,25
+26,27
0x3706 Not used
Timestamp
UINT32
UINT32
R
R
+28,29
+30,31
0x3707 Not used
Timestamp
UINT32
UINT32
R
R
+32,33
+34,35
0x3708 Not used
Timestamp
UINT32
UINT32
R
R
+36,37
+38,39
0x3709 Maximum kW import sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+40,41
+42,43
0x370A Maximum kvar import sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
+44,45
+46,47
0x370B Maximum kVA sliding window demand
Timestamp
0-Pmax U3
sec
UINT32
UINT32
R
R
