Satec PM172E - Configuring Communications in your Meter

60
Address Point ID Description Options/Range Units Type R/W Notes
+35 Action #2: Action target F14 UINT16 R/W
+36 Action #3: Action type F14 UINT16 R/W
+37 Action #3: Action target F14 UINT16 R/W
+38 Action #4: Action type F14 UINT16 R/W
+39 Action #4: Action target F14 UINT16 R/W
+40 Not used 0 UINT16 R/W
+41 Operate delay 0-9999
×0.1 sec
UINT16 R/W
+42 Release delay 0-9999
×0.1 sec
UINT16 R/W
+43 Not used 0 UINT16 R/W
352-395 Setpoint #1
396-439 Setpoint #2
440-483 Setpoint #3
484-527 Setpoint #4
528-571 Setpoint #5
572-615 Setpoint #6
616-659 Setpoint #7
660-703 Setpoint #8
704-747 Setpoint #9
748-791 Setpoint #10
792-835 Setpoint #11
836-879 Setpoint #12
880-923 Setpoint #13
924-967 Setpoint #14
968-1011 Setpoint #15
1012-1055 Setpoint #16
Data Log Setup
E
1792-1919
+0 Data log parameter #1 ID See Section 3.4 UINT16 R/W
+1 Data log parameter #2 ID UINT16 R/W
+2 Data log parameter #3 ID UINT16 R/W
+3 Data log parameter #4 ID UINT16 R/W
+4 Data log parameter #5 ID UINT16 R/W
+5 Data log parameter #6 ID UINT16 R/W
+6 Data log parameter #7 ID UINT16 R/W
+7 Data log parameter #8 ID UINT16 R/W
+8 Data log parameter #9 ID UINT16 R/W
+9 Data log parameter #10 ID UINT16 R/W
+10 Data log parameter #11 ID UINT16 R/W
+11 Data log parameter #12 ID UINT16 R/W
+12 Data log parameter #13 ID UINT16 R/W
+13 Data log parameter #14 ID UINT16 R/W
+14 Data log parameter #15 ID UINT16 R/W
+15 Data log parameter #16 ID UINT16 R/W
