59
Address Point ID Description Options/Range Units Type R/W Notes
the clock at the nearest whole
minute.
+8 Country code ITU calling number UINT16 R/W
+9 DST start hour 1-6 UINT16 R/W
+10 DST end hour 1-6 UINT16 R/W
Clock Indication and Setup
4352-4358
+0 Seconds 0-59 UINT16 R/W
+1 Minutes 0-59 UINT16 R/W
+2 Hour 0-23 UINT16 R/W
+3 Day of month 1-31 UINT16 R/W
+4 Month 1-12 UINT16 R/W
+5 Year (calendar year minus 2000) 0-99 UINT16 R/W
+6 Weekday 1-7 (1=Sun, 7=Sat) UINT16 R/W Ignored when written
Alarm/Event Setpoints Setup
352-1055
+0 Condition #1: Logical operator 0 = OR, 1 = AND UINT16 R/W
+1 Condition #1: Trigger parameter ID F12 UINT16 R/W
+2 Condition #1: Reserved 0 UINT16 R/W
+3 Condition #1: Reserved 0 UINT16 R/W
+4,5 Condition #1: Operate limit See Section 3.3 UINT32 R/W Scaled value
+6,7 Condition #1: Release limit See Section 3.3 UINT32 R/W Scaled value
+8 Condition #2: Logical operator 0 = OR, 1 = AND UINT16 R/W
+9 Condition #2: Trigger parameter ID F12 UINT16 R/W
+10 Condition #2: Reserved 0 UINT16 R/W
+11 Condition #2: Reserved 0 UINT16 R/W
+12,13 Condition #2: Operate limit See Section 3.3 UINT32 R/W Scaled value
+14,15 Condition #2: Release limit See Section 3.3 UINT32 R/W Scaled value
+16 Condition #3: Logical operator 0 = OR, 1 = AND UINT16 R/W
+17 Condition #3: Trigger parameter ID F12 UINT16 R/W
+18 Condition #3: Reserved 0 UINT16 R/W
+19 Condition #3: Reserved 0 UINT16 R/W
+20,21 Condition #3: Operate limit See Section 3.3 UINT32 R/W Scaled value
+22,23 Condition #3: Release limit See Section 3.3 UINT32 R/W Scaled value
+24 Condition #4: Logical operator 0 = OR, 1 = AND UINT16 R/W
+25 Condition #4: Trigger parameter ID F12 UINT16 R/W
+26 Condition #4: Reserved 0 UINT16 R/W
+27 Condition #4: Reserved 0 UINT16 R/W
+28,29 Condition #4: Operate limit See Section 3.3 UINT32 R/W Scaled value
+30,31 Condition #4: Release limit See Section 3.3 UINT32 R/W Scaled value
+32 Action #1: Action type F14 UINT16 R/W
+33 Action #1: Action target F14 UINT16 R/W
+34 Action #2: Action type F14 UINT16 R/W
