WARNING
To fix the wall plate, DO NOT use plastic or rubber anchor screws.
For cement or solid/hollow brick walls, use metal anchor screws Ø12 (NOT included).
ASSEMBLY INSTRUCTIONS (Fig. 6)
1. Take the wall plate out of the packaging (refer to Fig. 5) and take the drilling template

2.
Position the drilling template on the X-ray system installation wall, at the required
height (130 cm from the base is the suggested height)
3. Secure the template with adhesive tape
4. Check the holes for vertical and horizontal alignment, using a plumb line
5. Mark the wall plate anchor holes
6. Mark the holes for the electric cables connecting the timer to the tubehead
PLEASE NOTE
To prevent any flaking in the white coat and to control the center distances between the
holes, it is advisable to start drilling with a Ø7 bit, increasing this size gradually.
7. Drill the wall plate anchor holes
8. If required, drill the holes for the electric cables connecting the timer to the tubehead
9.
Remove the template  and insert the suitable anchor screws, according to the wall’s
characteristics 
10.
Unscrew the screw  and remove the plug  from the wall plate
11.
Withdraw the sliding cover 
12.
Apply the wall plate  to the wall and insert the screws  with the appropriate washers,
then tighten them alternately
13. Ensure that the wall plate is solidly attached to the wall
PLEASE NOTE
If the wall is not perfectly plumbed, insert a suitable shim between the wall and the wall
plate, in order to prevent warping.
5.2 ASSEMBLING THE WALL PLATE
