The “X-Mind
DC” X-ray system (Fig. 1) consists of:

TUBEHEAD

SPACER CONE

PANTOGRAPH-TYPE ARM

TIMER

WALL PLATE

BRACKET
OPTIONAL
− long 12” (31 cm) cone
− short 8” (20 cm) cone
− long cone 12” (31 cm) with a rectangular section sized 44x35mm
− second “CONTROL BUTTON” with extension cable
− RX signaling lamp for external use: X-Mind
LIGHT
− remote control button: X-Mind ECB
Fig. 1
1. “X-Mind DC” X-RAY SYSTEM






