Satelec X-Mind DC - Installation Procedure; System Component Unpacking

1
1
4
4
X
X
-
-
M
M
i
i
n
n
d
d
®
®
D
D
C
C
CAUTION
The “ X-Mind

DC

X-ray system must be installed by professionally trained technicians,
who must be able to certify their work with a Statement of Compliance.
WARNING
Prior to installing the X-ray system, it is advisable to ensure that all needed requirements
have been met (refer to §4 “INSTALLATION SPECIFICATIONS”)
The components of the “ X-Mind

DC ” radiographic system are duly packed within a carton box,
as shown in the following sketch (Fig. 5):
D
DOCUMENTS: INSTRUCTION MANUAL, INSTALLATION & MAINTENANCE MANUAL, AND WARRANTY CARD

X-Mind

DC TUBEHEAD PACKAGING

X-Mind

DC TIMER + RX SIGNALING LAMP FOR EXTERNAL USE X-Mind

LIGHT (OPTIONAL) + REMOTE
CONTROL BUTTON X-Mind

ECB (OPTIONAL) PACKAGING

PANTOGRAPH-TYPE ARM PACKAGING

WALL PLATE + BRACKET PACKAGING
PLEASE NOTE
Prior to installation, duly check all components.
PLEASE NOTE
The carton and the polystyrene foam can be completely recycled and can be disposed of by
authorized recycling companies.
PLEASE NOTE
The original packaging should be stored in the event the equipment is returned for repairs.
5. INSTALLATION
5.1 UNPACKING
