The following chart contains a list of error messages that may appear while the “X-Mind
®
DC” X-
ray system is operating.
The chart also includes the causes of the error messages and what to do to resolve them.
Error
Message
Cause Solution
RX1 TUBE HEAD
IS NOT CONNECTED OR IS OUT OF ORDER
CALL THE “SUPPORT DEPARTMENT”
RX2 TUBE HEAD
IS NOT CONNECTED OR IS OUT OF ORDER
CALL THE “SUPPORT DEPARTMENT”
CORRUPTED EEPROM DATA CALL THE “SUPPORT DEPARTMENT”
EEPROM DATA NOT PROPERLY SAVED CALL THE “SUPPORT DEPARTMENT”
LINE VOLTAGE VALUE NOT WITHIN THE SET
LIMITS
CALL THE “SUPPORT DEPARTMENT”
LINE VOLTAGE VALUE NOT INCLUDED WITHIN
THE ±15 % NOMINAL VALUE
CALL THE “SUPPORT DEPARTMENT”
THE “X-RAY” KEY
ALWAYS SEEMS TO BE DEPRESSED
ENSURE THAT IT IS NOT JAMMED
ANOMALY ON THE CONTROL PANEL CALL THE “SUPPORT DEPARTMENT”
THE EXPOSURE
HAS BEEN PREMATURELY INTERRUPTED
KEEP THE “X-RAY KEY”
DEPRESSED TILL THE END OF THE EXPOSURE
ANOMALY IN THE TRIAC/RELAY CALL THE “SUPPORT DEPARTMENT”
ANOMALY IN THE ELECTRONIC CIRCUIT CALL THE “SUPPORT DEPARTMENT”
ANOMALY IN THE CONTROL CIRCUIT CALL THE “SUPPORT DEPARTMENT”
INCORRECT DIP SWITCH CONFIGURATION CALL THE “SUPPORT DEPARTMENT”
THE “CONTROL BUTTON” DOES NOT
CORRESPOND TO THE SELECTED TUBE HEAD
USE THE “CONTROL BUTTON” THAT CORRESPONDS
TO THE SELECTED TUBE HEAD
THE TUBEHEAD
DOES NOT WORK PROPERLY
CALL THE “SUPPORT DEPARTMENT”
THE TUBEHEAD
IS NOT IN THE CORRECT MODE
CALL THE “SUPPORT DEPARTMENT”
