CAUTION
This must be done by the installer.
WARNING
To make the changes operative, turn off the timer and then turn it on again.
To change the configuration, the timer’s dip switch positions (
)must be changed:
DIP
SWICH
PARAMETER ON OFF
1 TUBEHEAD No. 1 INSTALLED NOT INSTALLED
2 TYPE OF TUBEHEAD No. 1
dc
DIRECT CURRENT
AT CONSTANT POTENTIAL
ac
ALTERNATING CURRENT
SINGLE-PHASE
3 TUBEHEAD No. 2 INSTALLED NOT INSTALLED
4 TYPE OF TUBEHEAD No. 2
dc
DIRECT CURRENT
AT CONSTANT POTENTIAL
ac
ALTERNATING CURRENT
SINGLE-PHASE
5 No. 2 CONTROL BUTTON INSTALLED NOT INSTALLED
6 CONE LONG (12”) SHORT (8”)
7 NOT AVAILABLE NOT AVAILABLE
8 NOT AVAILABLE NOT AVAILABLE
8. CHANGING THE CONFIGURATION
