1. CHANGING THE NUMBER OF TUBEHEADS INSTALLED
To change the number of tubeheads installed, move dip switch no. 1 or no. 3
a
.
If the tubehead is connected to the X-RAY 1 terminal board, put dipswitch no. 1 in the
ON position; if not, put it in the OFF position
b
.
If the tubehead is connected to the X-RAY 2 terminal board, put dip switch no. 3 in the
ON position; if not, put it in the OFF position
2. CHANGING THE TYPE OF TUBE HEAD
The following timer connections may be made:
no. 2 TUBEHEADS USING ALTERNATING CURRENT “ac”: “X-Mind
®
AC”
or
no. 2 TUBEHEADS USING DIRECT CURRENT “dc”: “X-Mind
®
DC”
or
no. 1 TUBEHEAD USING ALTERNATING CURRENT “ac” + no. 1 TUBE HEAD USING DIRECT
CURRENT “dc”: “X-Mind
®
AC” + “X-Mind
®
DC”
To change the type of tubehead, move dip switch no. 2 or no. 4
a
.
If tubehead RX1 is “ac”, put dip-switch no. 2 in the OFF position, otherwise put it in the
ON position
b
.
If tub head RX2 is “ac”, put dip-switch no. 4 in the OFF position, otherwise put it in the
ON position
3. CHANGING THE CONE
To replace the long 12” cone with the short 8” cone, move dip switch no. 6 to the OFF
position.
Check that the “8” LED lights up on the control panel.
PLEASE NOTE
After modification, the set exposure times are automatically changed.
To replace the short 8” cone with the long 12” cone,
move dip switch no. 6 to the ON position.
Check that the “12” LED lights up on the control panel.
PLEASE NOTE
After modification, the set exposure times are automatically changed.
4. CHANGING THE REMOTE BUTTONS SETTINGS
To change the control buttons settings, move dip switch no. 5 to the ON position.
PLEASE NOTE
After modification, each tube head is controlled by its button.
