5. CHECKING THE POWER ABSORBED BY THE X-RAY SYSTEM
To check the power absorbed by the radiographic system a tester must be used, in the
mode ampmeter in “AC”
a. Connect the instrument to the power supply line
(refer to § 5.9 “TIMER ELECTRIC CONNECTION”)
b. Set an exposure time of approx. 3 sec on the timer
c. Take an exposure and read the current value on the display
PLEASE NOTE
The X-ray system complies with the requirements when
the absorbed current is ≤ 8A with 230V line voltage (±15%)
the absorbed current is ≤ 12.5A with 115V line voltage (±15%)
Otherwise, check the electrical system or call the “Support Department”.
6. CHECKING THE ELECTRIC SYSTEM
To check the electric system, a tester must be used, in the mode voltmeter in “AC”
a. Connect the instrument to the L and N terminals on the timer
b. Measure the line voltage (V
0
)
c. Connect the instrument to the L and N terminals of the wall plate terminal board
(refer to § 5.5 “CONNECTION TO THE FEEDING TERMINAL BOARD”)
d. Set an exposure time of approx. 3 sec on the timer
e. Proceed with the exposure
f. Measure the line voltage during exposure (V
1
)
PLEASE NOTE
The electrical system complies with the requirements when the result of the
formula
(V
0
– V
1
) / V
0
is ≤ 0.03 (3%)
Otherwise, the electric system must be adjusted.
(refer to § 4 “INSTALLATION SPECIFICATIONS”
