Section 9: Basic Specifications
CG2 Series Quick Guide Page 9-3
Self-diagnostic
function
- Broken head element check
- Paper end detection
- Cover open detection
- Test print
- Broken head element check
- Paper end detection
- Cover open detection
- Test print
- Ribbon end detection
- Ribbon near-end detection
Dimensions 5 in (W) x 9 in (D) x 7 in (H)
128 (W) × 235 (D) × 173 (H) (mm)
Weight 3.3 pounds (1.5 kg) 3.5 pounds (1.6 kg)
Power
specifications
AC adapter
Input power voltage: AC 100 to 240 V ±10%
Power consump-
tion
60 W (In standby: 2.5 W)
Environmental
conditions (Tem-
perature/
Humidity)
Operating environment: 32°F to 95° (0 to 35°C), 30 to 80% RH (However, no
condensation)
Storage environment: 14°F to140°F (–10 to 60°C), 15 to 85% RH (However, no
condensation)
(Not including ribbon, labels, and other supplies.)
Options - Cutter unit
- Dispenser unit
- Wireless LAN (802.11b/g Auto switch) interface (External)
- Keypad
Interface Select one of the following. (The factory will provide the unit with the
selected interface.)
1
USB (Full speed) and RS-232C (D-SUB 9-pin)
2
USB (Full speed) and LAN (10 BASE/100 BASE-TX auto switching)
* The RS-232C connector can be used to connect the printer to a computer
or the keypad.
LED ON LINE (POWER) (Green/Red)
Operation button Button: POWER, FEED/LINE
Potentiometer for
adjustment
- I-mark sensor adjustment (Adjusts the sensor slice level.)
- Label gap sensor adjustment/Center tag hole sensor adjustment (Adjusts
the sensor slice level.)
- Cut position adjustment (Can only be adjusted when the cutter unit is attached.)
- Label dispenser stop position adjustment (Can only be adjusted when the
dispenser unit is attached.)
Paper length
detection sensor
I-mark sensor (Reflective type)
Label gap sensor (Transmissive type)
Noise (EMC)
standard
FCC15B Class B, CE (EN55022, EN55024), GB9254-1998, GB17625.1 (2003),
KN22, KN24
Model name CG208 DT CG212 TT CG208 TT CG212 TT
