Sauer Danfoss H1 - Dimensions Input Shafts; Option G4, ISO 3019-1, Flange Outer Dia 22 MM-4 (SAE B, 13 Teeth); Option G5, ISO 3019-1, Flange Outer Dia 25 MM-4 (SAE B-B, 15 Teeth)

22
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Dimensions
Input Shafts Option G4, ISO 3019-1, ange outer dia 22 mm-4 (SAE B, 13 teeth)
Option G5, ISO 3019-1, ange outer dia 25 mm-4 (SAE B-B, 15 teeth)
Speci cations
Option Spline
Min active spline
length
2
Torque rating
1
Rated torque Maximum torque
mm [in] Nm [lbf•in] Nm [lbf•in]
G4 13 teeth, 16/32 pitch 16.5 [0.65] 180 [1600] 222 [1970]
1)
For de nitions of maximum and rated torque values, refer to:
Basic Information Manual 11062168, section Shaft Torque Ratings and Spline Lubrication.
2)
Minimum active spline length for the speci ed torque ratings. T301 005E
Speci cations
Option Spline
Min active spline
length
2
Torque rating
1
Rated torque Maximum torque
mm [in] Nm [lbf•in] Nm [lbf•in]
G5 15 teeth, 16/32 pitch 22.0 [0.866] 277 [2450] 370 [3270]
1)
For de nitions of maximum and rated torque values, refer to:
Basic Information Manual 11062168, section Shaft Torque Ratings and Spline Lubrication.
2)
Minimum active spline length for the speci ed torque ratings. T000 183E
Mounting ange
Flange 101-2
Per ISO 3019-1 (SAE B)
Spline data
Number of teeth : 13
Pitch fraction : 16/32
Pressure angle : 30°
Pitch ∅ : ∅20.6375
Type of t : llet root side
Per : ansi b92.1b class 6e
∅22.085
±0.09
33 ±0.68
8 ±0.8 Mating coupling
Must not protrude
Beyond this point
16. 5 ±0.15
∅18.5
±0.12
Paint free
∅74.3 MIN
P700 33 266
mm
[in]
Mounting ange
Flange 101-2
Per ISO 3019-1 (SAE B)
∅21.98 ±0.12
8 ±0.8
Mating coupling
Must not protrude
Beyond this point
38 ±0.68
Spline data
Number of teeth : 15
Pitch fraction : 16/32
Pressure angle : 30°
Pitch ∅ : ∅23.813
Type of t : llet root side
Per : ansi b92.1b class 6e
∅25.23 ±0.09
22 ±0.15
Paint free
∅74.3 Min
P700 33 267
