Sauer Danfoss H1 - Model Code

8
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
General Technical Specications
A B D F E G H J K M N S T V W X Y
H1 P A
Displacement
045 45 cm³ [2.75 in³]
053 53.8 cm³ [3.28 in³]
A Rotation
L Left hand (counter clockwise)
R Right hand (clockwise)
B Product Version
A Revision code
D Control
A2 Electric Displacement Control (EDC) 12V, Deutsch connector
A3 Electric Displacement Control (EDC) 24V, Deutsch connector
A4 Electric Displacement Control (EDC) 12V, Deutsch connector, Manual override
A5 Electric Displacement Control (EDC) 24V, Deutsch connector, Manual override
A9 Forward-Neutral-Reverse (FNR) 12V, Deutsch connector, Manual override
B1 Forward-Neutral-Reverse (FNR) 24V, Deutsch connector, Manual override
A8
Non Feedback Proportional Electric (NFPE) 12V, Deutsch connector, Manual override
(align with option E: Displacement Limiters & option W: Special Hardware)
B8
Non Feedback Proportional Electric (NFPE) 24V, Deutsch connector, Manual override
(align with option E: Displacement Limiters & option W: Special Hardware)
A7
AC-1 (Automotive), 12V, Manual Override (align with option E: Displacement Limiters & option W:
Special Hardware)
C2
AC-1 (Automotive), 24V, Manual Override (align with option E: Displacement Limiters & option W:
Special Hardware)
F Orices
C1 Orices, 0.8 mm in servo supply 1 and 2, recommended for propel applications
C2 Orices, 1.3 mm in servo supply 1 and 2 (Standard), recommended for propel applications
C3 No orice, recommended for non-propel applications
E Displacement limiters
N None
C
No limiters, with nested springs (required for NFPE) (align with option Y: Settings for adjustment, if
applicable)
B Adjustable externally (align with option Y: Settings for adjustment, if applicable)
D Adjustable externally with nested springs, required for NFPE
G Endcap options
Twin port
High
pressure
ports
ISO 11 926 O-ring ports ISO 6162 split ange ports
Match
with below
options
(M+N)
With pressure limiter
Without pressure
limiter
(HPRV only)
With pressure limiter
Without pressure
limiter
(HPRV only)
Match
with below
options (T)
Suction
ltration
Remote and
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote or
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote and
external
charge supply
for full charge
ow ltration
Suction
ltration
Remote or
external
charge supply
for full charge
ow ltration
D6 X
D8 X
E5 X
E6 X
E9 X
F1 X
F2 X
F3 X
Model Code
