Sauer Danfoss H1 - External Full Flow Charge Pressure Filtration, Option E

42
11063344 • Rev EA • Dec 2012
H1 Axial Piston Pump, Size 045/053, Single
Technical Information
Installation Drawings
Please contact Sauer-Danfoss for specic installation drawings
Installation Drawings
(continued)
External full ow charge pressure ltration, option E
Filtration
93.5 ±0.8
Charge ltration port "E"
Port ISO 11926-1 - 7/8-14
from lter
15°
(199.8)
199.8 ±1.2
60 ±0.8
6 ±0.5
P700 45 735
A-A
A A
mm
