Currency Discrimination Fitness Sorter SB - 2000 Service Manual
36
8. Set Function and its Parameters
1. ERROR STOP CTRL.
2. SENSOR LEVEL CTRL.
3. SYSTEM REPORT
4. SET A/S CALL No.
5. SHADING
6. CF & MODE SET
7. FITNESSITEM SET
8-1. SERVICE MENU 1
There are ‘Service Menu1’ and ‘Service Menu2’.
Service Menu1 includes mainly the menu adjusting Parameter of Sensors.
How to enter SERVICE MENU 1:
Service Menu 1
< Display of SERVICE MENU 1>
1. ERROR STOP CTRL. 1) ERROR STOP ON 2) ERROR STOP OFF
2. SENSOR LEVEL CTRL.
1) HOPPER LEVEL 2) DOUBLE LEVEL
3. SYSTEM REPORT
1) COUNTING REPORT 2) MAIN S/W VERSION
3) IMAGE S/W VERSION 4) S/N DISPLAY
5) S/N SETTING
4. SET A/S CALL No.
5. SHADING 1) CIS 2) IR 3) UV 4) MR 5) CAP
6. CF & MODE SET 1) UV SET 2) MR SET 3) IR SET 4) MODE SET
5) FIT PASS SET
7. FITNESS SETTING
Press :
MENU
MODE
CODE : 55757
To exit from the current function, press ‘MENU’ key and to move SERVICE MENU2, press ‘DISPLAY’ key.
