SBM SB-2000 - MR Shading Procedure

Currency Discrimination Fitness Sorter SB - 2000 Service Manual
58
5. SHADING
1. CIS
2. IR
3. UV
4. MR
5. CAP
WARNING
FOR PROPER SHADING
REFER TO THE SVC
MANUAL
PRESS ESC TO CANCEL
PRESS ENTER TO GO
9-4. MR SHADING
<MR SHADING SHEET: Real Banknote ‘US$ 1’ >
MENU
MODE
5
CODE : 55757
4
Place 1~5 bills of US$1 on the
hopper with the same direction as
shown on the left figure.
Select the 4. MR
Press ‘START’ key
