16. Assembly Drawings
16 - 1. TOP LEVEL
16 - 2. ASS'Y COVER PANEL
16 - 3. ASS'Y COVER TOP
16 - 4. ASS'Y POCKET UPPER
16 - 5. ASS'Y POCKET LOWER
16 - 6. ASS’Y UPPPER & LOWER BODY
16 - 7. ASS’Y UPPPER BODY 1
16 - 8. ASS'Y PLATE GUIDE UPPER
16 - 9. ASS’Y LOWER BODY
16 - 10. ASS'Y PLATE GUIDE LOWER
16 - 11. ASS'Y PLATE BASE
16 - 12. ASS'Y SELECTOR
16 - 13. ASS'Y SMPS UNIT
16 - 14. ASS'Y BKT MOTOR STACKER
16 - 15. ASS’Y UPPPER BODY 2
16 - 16. ASS'Y SHAFT ADF ADJUST
16 - 17. ASS'Y SEPARATOR
16 - 18. ASS’Y UPPPER BODY 3
16 - 19. ASS'Y GUIDE IN LOWER
16 - 20. ASS'Y GUIDE IN UPPER
16 - 21. ASS'Y REAR BODY
16 - 22. ASS'Y BLOCK TAPE DETECT
16 - 23. ASS'Y_BKT_DETECTOR_V
Parts required to handle with care.
ASS'Y_BLOCK_TAPE_DETECT (Apt to be deformed or scratched
in dropping or making a collision.)
ROLLER_DETECT_TAPE (same as above)
PLATE_SPRING_DETECTOR (Required Not Folded)
