Currency Discrimination Fitness Sorter SB - 2000 Service Manual
50
9. SHADING
What is shading?
Shading is to make a full swing reference waveform to read the full level of a signal. If the
machine rejects too many notes in Mixed Mode or in CF Detection Mode, the system
might not analyze the input of waveform. It is possible to make a standard waveform for
the system.
5. SHADING
1. CIS
2. IR
3. UV
4. MR
5. CAP
ATTENTION :
Before shading, make sure to clean all sensors.
Then, please carry out ‘LOAD DEFAULT’ in following order.
Press :
MENU
9
CLEAR
1
< Display of SHADING MENUS >
