Currency Discrimination Fitness Sorter SB - 2000 Service Manual
91
15-2-13. CONNECTOR (Front Side)
15-2-14. CAP_RECEIVE (Front Side)
CONN_V1.1 (Front Side)
CAP_RECEIVE V2.0 (Front Side)
COMPARATOR
FET
OP-AMP
